Product details
Bently Nevada Vibration Transmitter
This heavy-duty transmitter turns vibration data into 4-20mA signals for easy equipment health checks. CSA Division 2 certified for explosive areas, 990-10-50-03-01 uses DIN clips and screws for flexible mounting. Works best with rotating machinery like compressors and fans in oil/gas plants.
🔍 Model Breakdown: 990-10-50-03-01
- 10 → 0-250µm measurement range
- 50 → 5m sensor cable
- 03 → DIN rail + screw mount
- 01 → CSA Div 2 approval
📏 Measurement Specs
- ▶ 5Hz-6kHz frequency range
- ▶ 0.5-1.75mm probe gap
- ▶ 9.5mm min target size
- ▶ ±1.5% signal accuracy
⚡ Power & Safety
- ▶ 12-35VDC input
- ▶ 23mA current limit
- ▶ 1,000Ω max loop
- ▶ ATEX Zone 2 rated
✅ Key Features
- ◆ Dual mounting (DIN rail + screws)
- ◆ 100µs fault detection
- ◆ 3-second auto-recovery
- ◆ Optional COO certificate
