Product details
High-Power Industrial Drive: Toshiba VFAS3-4110KPC
The Toshiba VFAS3-4110KPC delivers robust 150 HP motor control. This AS3 series drive is built for demanding industrial automation. It offers flexible communication and precise control.
Quick Summary & Key Specs
- Core Model: Toshiba VFAS3-4110KPC (AS3 Series)
- Power: 150 Horsepower (HP)
- Voltage: 460 VAC, Three-Phase Input & Output
- Current: 211A (250A Variable Torque)
- Control: V/Hz, FOC, Encoder, or Torque Mode
- Communication: Dual Ethernet (EtherNet/IP, Modbus TCP) & RS-485
- Frame & Enclosure: A6 Frame, Open Chassis (IP00)
- Safety: Integrated Safe Torque Off (STO)
Extended Technical Parameters
- Output Frequency Range: 0.1 Hz to 590 Hz
- Carrier Frequency: Adjustable from 1 kHz to 8 kHz
- Analog Inputs: 3 channels (0-20mA / +/-10VDC)
- Analog Outputs: 2 channels (0-20mA / 0-10VDC)
- Digital Inputs: 8 points, 24VDC Sinking/Sourcing
- Digital Outputs: 3 Relay points (2A/point)
- Temperature Range: -15°C to 50°C
- Built-in Features: DC Reactor, EMC/EMI Filter
- Required Option: External Dynamic Braking Unit
- Optional Cards: EtherCAT, Encoder, Additional I/O
Service & Logistics Details
- Warranty: This product is covered by a standard 12-month warranty.
- Global Shipping: We deliver worldwide using reliable couriers.
- Available Carriers: Options include FedEx, UPS, and DHL services.
- Battery Note: Unit contains a user-replaceable CR2032 lithium battery.
Expert Application FAQs
- What is the main advantage of the AS3 series for large systems?
- The VFAS3-4110KPC offers built-in Ethernet/IP and Modbus TCP. This allows direct integration into modern plant networks without extra gateways.
- Can this drive control a permanent magnet (PM) motor?
- Yes, its Field Oriented Control (FOC) and encoder feedback modes are suitable for high-performance control of PMAC motors.
- How do I handle regenerative braking energy?
- An external dynamic braking unit (resistor) is required to dissipate regenerative power from the motor during deceleration.
- Is the built-in EMC filter sufficient for CE compliance?
- The integrated filter provides a good base. Final system compliance depends on proper installation, cabling, and cabinet shielding.
- What’s the purpose of the user sequence programming?
- This feature allows creating simple logic sequences (like timers) inside the drive. It can reduce the need for a small external PLC in some applications.
- Ready to integrate this powerful drive? Contact our technical sales team for expert support.
