Siemens 6SL3210-1PE33-0AL0 PM240-2 Power Module – 160kW

Siemens 6SL3210-1PE33-0AL0 PM240-2 FSG-C2 160kW Power Module – Efficient, Reliable, and Compact

The Siemens 6SL3210-1PE33-0AL0 PM240-2 power module delivers reliable performance for SINAMICS G120 and S120 systems. It features an integrated EMC Class C2 filter and a built-in braking chopper for precision motor control. With excellent energy efficiency, this module is built for demanding industrial environments.

⚙️ Main Specifications

• Model: 6SL3210-1PE33-0AL0
• Series: SINAMICS PM240-2 FSG-C2
• Power Rating (LO): 160 kW
• Power Rating (HO): 132 kW
• Voltage: 3AC 380–480 V ±10%
• Frequency: 47–63 Hz
• Current (LO): 302 A | (HO): 250 A
• Max Output Current: 500 A
• Efficiency: 0.98
• Power Factor: 0.9

⚡ Overload Capacity

• Low Overload (LO): 150% for 3s, 110% for 57s, 100% for 240s
• High Overload (HO): 200% for 3s, 150% for 57s, 100% for 240s
• Cycle Time: 300 s

📊 Technical Details

• Pulse Frequency: 2 kHz
• Output Frequency (Vector): 0–200 Hz
• Output Frequency (V/f): 0–550 Hz
• Cooling: Internal air cooling
• Cooling Air Flow: 0.210 m²/s
• Sound Level: 75 dB (at 1 m)
• Power Loss: 3.66 kW
• Filter Class: EMC Class A (integrated)

🌡 Ambient & Environmental Data

• Operating Temp (LO): -20°C to +40°C
• Operating Temp (HO): -20°C to +50°C
• Storage Temp: -40°C to +70°C
• Humidity: Max 95%, non-condensing
• Altitude: Up to 1000 m
• Protection Class: IP20

📦 Dimensions & Weight

• Size (H×W×D): 1000 × 305 × 357 mm
• Package Size: 1190 × 395 × 591 mm
• Net Weight: 107 kg

🚀 Key Advantages

• High overload tolerance for dynamic performance
• Integrated EMC C2 filter reduces electrical noise
• Built-in braking chopper for efficient energy use
• Compact, easy to install, and durable IP20 design
• Ideal for high-power industrial drives
• Supports firmware V4.7 SP9 and V5.1

📜 Compliance

• RoHS Compliant since 2018
• REACH Regulation: Lead, Cadmium oxide declared
• WEEE Take-Back Obligations: Yes
• SCIP Number: 5edcc585-8cfb-4f2e-aebe-a206f71873ff

📞 Warranty & Support

• Warranty: 12 Months
• Shipping Options: FedEx, UPS, DHL
• Contact: sales@powergearx.com
• WhatsApp: +86 18030005825

💬 FAQ

• Q1: What is the power rating of the 6SL3210-1PE33-0AL0?
• A: It provides 160 kW (LO) or 132 kW (HO) output power depending on load conditions.
• Q2: Can I use this module with SINAMICS G120 and S120 systems?
• A: Yes, it is designed for both G120 and S120 inverter platforms.
• Q3: Does it include a braking chopper?
• A: Yes, it has a built-in braking chopper for efficient motor deceleration.
• Q4: Is the filter EMC compliant?
• A: It includes an integrated EMC Class C2 filter for noise reduction.
• Q5: What firmware versions are supported?
• A: Compatible with CU firmware versions V4.7 SP9 and V5.1.
