Siemens 6ES7214-1BD23-0XB0 CPU 224 | SIMATIC S7-200 PLC with 14DI/10DO Relay Outputs

Reliable Compact Controller for Versatile Automation

The Siemens 6ES7214-1BD23-0XB0 is a durable CPU 224 unit from the SIMATIC S7-200 series. This compact PLC uses AC power and provides 14 digital inputs and 10 relay outputs. It is perfect for small to medium control tasks in manufacturing, packaging, and building management. Our unit is new, original, and ready for fast delivery.

Detailed Technical Data

• Brand: Siemens
• Model: 6ES7214-1BD23-0XB0 (CPU 224)
• Series: SIMATIC S7-200
• Type: Compact CPU with AC Supply & Relay Outputs
• Supply Voltage: 120/230V AC (47-63 Hz)
• Digital Inputs: 14 points, 24V DC (sink/source)
• Digital Outputs: 10 points, Relay (2A per point)
• Program Memory: 12 KB
• Data Memory: 8 KB (backed by super capacitor, optional battery for 100 hours)
• Expansion Capability: Up to 7 modules for digital (max 168 I/O) or analog (max 35 I/O) extension.
• High-Speed Functions:
  • 6 counters (up to 30 kHz)
  • 4 interrupt inputs
  • 2 pulse outputs
• Communication Ports: 1x RS-485 (supports PPI, MPI, and Freeport protocols)
• Programming Languages: Ladder Logic (LAD), Function Block Diagram (FBD), Statement List (STL)
• Real-Time Clock: Integrated
• Operating Temperature:
  • Horizontal mount: 0°C to 55°C
  • Vertical mount: 0°C to 45°C
• Storage Temperature: -40°C to 70°C
• Protection Class: IP20
• Dimensions (W x H x D): 120.5 mm x 80 mm x 62 mm
• Weight: Approx. 410 g

Key Features & Advantages

• Robust Relay Outputs: Directly switch AC/DC loads up to 2A, simplifying control of contactors and small motors.
• Wide AC Voltage Range: Connects to both 120V and 230V AC mains without adjustment.
• Strong Expandability: Connect up to 7 I/O modules for a highly customized system.
• Fast Processing: 0.22 µs per bit instruction for quick response.
• Proven Reliability: Backed by Siemens’ quality, ideal for harsh industrial environments.

Package & Service Commitment

• Genuine Siemens 6ES7214-1BD23-0XB0 CPU module.
• New and original, in factory packaging.
• Warranty: Full 12-month warranty against defects.
• Shipping: Reliable global delivery via FedEx, UPS, or DHL.

Author: Powergear X Automation

Frequently Asked Questions

• What is the main advantage of relay outputs in this CPU?
• Relay outputs can switch both AC and DC loads, providing great flexibility for controlling different devices like lights, solenoid valves, and small motor starters without extra relays.
• Can I connect this CPU to a PROFIBUS DP network?
• Yes, this CPU is PROFIBUS DP extendable. You need an additional EM 277 PROFIBUS DP module to connect it as a slave station.
• How do I maintain the program and data during a power outage?
• The unit has a super capacitor for short-term backup (typically a few days). For longer backup (up to 100 hours), you must install an optional battery.
• What is a common mistake when wiring the relay outputs?
• Exceeding the switching capacity (2A resistive) or not using a protective fuse. Always check the load current and inductive kickback from coils.
• Can I use this CPU for high-speed counting applications?
• Yes, with its 30 kHz counter inputs, it is suitable for tasks like counting encoder pulses from a conveyor belt or packaging machine.
