SIMATIC ET 200SP DQ Module: Reliable Digital Power
This is the 6ES7132-6BF01-0BA0 digital output module. It is part of the SIMATIC ET 200SP system. It gives you eight powerful outputs. Each output handles 24V DC and 0.5A. It is built for standard factory tasks. The module offers strong diagnostics. It helps keep your machines running smoothly.
Key Product Advantages
- Eight Solid Outputs: Control eight devices like valves or relays easily.
- Built-in Safety: Module has short-circuit and wire break detection.
- Easy to Set Up: Works with BaseUnit A0. Simple color coding (CC02).
- Trusted Performance: Made by Siemens for reliable industrial use.
- Clear Status Lights: Green LEDs show power and channel status.
Technical Specifications
- Brand: Siemens
- Article Number: 6ES7132-6BF01-0BA0
- Product Type: DQ 8x24VDC/0.5A ST
- Module Function: Digital Output (PNP, Sourcing)
- Output Channels: 8
- Output Current: 0.5 A per channel
- Total Module Current: Max 4 A
- Output Voltage: 24V DC
- Switching Frequency: Up to 100 Hz (resistive load)
- Response Time: ≤100 µs (turn off)
- Supply Voltage: 24V DC (19.2V – 28.8V range)
- Power Loss: Typically 1 W
- Connection: Uses BaseUnit Type A0 (Color Code CC02)
- Bus Connection: PROFINET (via ET 200SP interface)
- Diagnostics: Yes. For short circuit, wire break, supply voltage.
- Isolation: 707 V DC (tested between channels and bus)
- Operating Temperature: -30°C to +60°C (horizontal mount)
- Width: 15 mm
- Weight: Approx. 30 g
- Safety Standards: Can be used for safety functions up to SIL 2, PL d.
- Software Support: STEP 7 (TIA Portal V14+), PCS 7, PROFINET GSDML.
Installation & System Fit
This module snaps onto a BaseUnit A0. The color code is CC02. It fits in a standard ET 200SP station. You can connect it with 1 to 4 wires. Use shielded cables for long runs. It works in both horizontal and vertical positions.
Diagnostics & Protection Features
- Green PWR LED shows good power.
- Green channel LEDs show active outputs.
- DIAG LED signals module errors.
- Detects short circuits to ground or L+.
- Warns about broken wires.
- Can output a preset substitute value.
Ordering & Support Details
You get one DQ module in the package. It comes with full documentation. We provide a 12-month warranty. We ship fast worldwide using FedEx, UPS, and DHL.
Expert Questions & Answers
- Q: Can I use this module to directly control a small motor?
- A: Yes, for small DC motors under 0.5A. Always use an external fuse for extra protection.
- Q: How does it handle a broken wire on an output?
- A: The module’s diagnostics can detect a wire break and send an alarm to the PLC.
- Q: Is it safe to use in a high-vibration area?
- A: The ET 200SP design is robust. For extreme vibration, ensure the BaseUnit is securely locked.
- Q: What’s a common mistake during setup?
- A: Forgetting to set the substitute value behavior in the software. This can cause unexpected machine states on a fault.
- Q: Can two outputs be used together for one device?
- A: Yes, outputs can be paralleled for redundant control, but not to increase current (uprating).
