Compact & Reliable Digital Input Module
The Siemens 6ES7131-4BD00-0AA0 is a high-quality 24V DC digital input module. Specifically, it is designed for the ET 200S distributed I/O system. Moreover, this module provides four isolated channels in a compact 15mm housing. Consequently, it ensures reliable signal acquisition for your standard control applications.
Technical Specifications
- Article Number: 6ES7131-4BD00-0AA0
- Product Designation: SIMATIC ET 200S, 4 DI Standard 24V DC
- Module Width: 15 mm
- Number of Channels: 4 digital inputs
- Input Voltage: 24 V DC (Nominal)
- Signal “1” Range: +15 to +30 V DC
- Signal “0” Range: -30 to +5 V DC
- Input Current (at 24V): Typically 7 mA per channel
- Input Delay: 2 ms to 4.5 ms (typically 3 ms)
- Encoder Supply: Up to 500 mA from L+ (for sensor power)
- Electrical Isolation: 500 V DC between channels and backplane bus
- Permissible Potential Difference: 75 V DC / 60 V AC
- Cable Length (Shielded): Up to 1000 meters
- Power Loss: Typically 0.7 W
- Dimensions (H x W x D): 81 x 15 x 52 mm
- Weight: Approximately 35 grams
What You Will Receive
- 5 x Siemens 6ES7131-4BD00-0AA0 digital input modules (factory pack).
- Condition: New and original, in factory packaging.
- Warranty: Full 12-month warranty against defects.
- Shipping: Fast delivery via FedEx, UPS, or DHL with tracking.
Easy Integration & Use
- First, snap the module onto a standard ET 200S base unit.
- Then, connect your 24V DC sensors, switches, or buttons to the terminals.
- Subsequently, the module is automatically recognized by the SIMATIC controller (with appropriate GSD file).
- Moreover, no software parameterization is needed for standard operation.
- Finally, the green LEDs provide immediate visual feedback on each input’s status.
System Compatibility
- Designed exclusively for the SIMATIC ET 200S distributed I/O system.
- Additionally, it can be used with Siemens S7-300, S7-400, S7-1500, and other PROFIBUS DP masters.
- Furthermore, it is compatible with STEP 7 (TIA Portal and Classic) engineering software.
Frequently Asked Questions
What type of sensors can I connect to this module?
Generally, you can connect standard 2-wire or 3-wire 24V DC sensors, mechanical switches, and proximity switches that meet the specified voltage ranges.
Does this module provide power to the connected sensors?
Yes, it can supply up to 500 mA from the L+ terminal. Specifically, this powers connected 2-wire sensors across all channels.
What is the difference between this and a high-speed input module?
This is a standard input module with a typical response time of 3ms. In contrast, high-speed modules have much faster response times (microseconds) for time-critical applications.
Can I use one channel independently if others fail?
The channels share a common power supply but are electrically independent for signals. Therefore, a fault on one channel (e.g., short circuit) typically does not affect the others.
From experience, what is a common wiring mistake to avoid?
Commonly, exceeding the total 500mA sensor supply current for all connected devices is an issue. Thus, always calculate the sum of all sensor currents to avoid overloading the internal supply.
Is diagnostic information available for this module?
No, this standard module has no diagnostic data. Instead, it only provides the binary input state. For wire-break or short-circuit detection, consider diagnostic input modules.
What is the meaning of the packaging unit (5 pieces)?
The module is sold in a factory-sealed pack containing 5 identical units. Consequently, this is convenient for stocking and projects requiring multiple identical modules.
