Siemens 6AR1303-0ED00-0AA0 Module | PROFIBUS DP

Siemens PROFIBUS & Ethernet Communication Module

• Part Number: 6AR1303-0ED00-0AA0
• This module provides dual network connectivity for industrial systems.
• It supports both PROFIBUS DP and standard Ethernet communication.
• Compact plug-in design makes integration simple and fast.
• Perfect for upgrading or expanding automation network capabilities.
• Engineered by Siemens for reliable performance in demanding environments.

Core Benefits & Why Choose This Module

• Dual Network Gateway: Bridges PROFIBUS DP devices to Ethernet networks seamlessly.
• High-Speed Data Transfer: Up to 12 Mbit/s on the PROFIBUS DP side.
• Low Power Design: Consumes less than 2 Watts, reducing cabinet heat.
• Robust Connectivity: Auto-negotiating 10/100 Mbit/s Ethernet with RJ45 port.
• Enhanced Diagnostics: LED status indicators for quick visual health check.
• Wide Temperature Tolerance: Operates from -20°C to +60°C.

Complete Technical Data Sheet

• Manufacturer & Model: Siemens 6AR1303-0ED00-0AA0
• Product Type: Communication Interface Module
• Supported Networks: PROFIBUS DP & Industrial Ethernet
• PROFIBUS DP Data Rate: Up to 12 Mbit/s (9.6 kbit/s to 12 Mbit/s)
• Ethernet Interface: 1 x RJ45, 10/100 Mbit/s, Auto-MDI/MDIX
• Power Supply: 24 V DC (Nominal)
• Power Consumption: ≤ 2 W (Maximum under full load)
• Electrical Isolation: Integrated for signal protection
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +70°C
• Relative Humidity: 10% to 95% (non-condensing)
• Vibration Resistance: Compliant with IEC 60068-2-6
• Shock Resistance: Compliant with IEC 60068-2-27
• Dimensions (WxHxD): Approx. 40 mm x 125 mm x 75 mm (est.)
• Weight: Approximately 200 grams
• Certifications: CE, cULus, RoHS compliant
• Protocol Standards: PROFIBUS DP according to EN 50170

Simple Installation & Setup Guide

• Mount the module on a standard DIN rail inside your control cabinet.
• Connect the 24V DC power supply to the designated terminals.
• Plug the PROFIBUS DP cable into the 9-pin D-Sub connector.
• Connect the Ethernet cable to the RJ45 port for network integration.
• Use the DIP switches or software to set the PROFIBUS address.
• The LEDs will indicate successful power-up and network status.

System Compatibility Notes

• Compatible with Siemens SIMATIC S7-300/400/1200/1500 PLC systems.
• Acts as a slave on PROFIBUS DP and a device on Ethernet networks.
• Can be used to connect legacy PROFIBUS equipment to modern SCADA systems.
• Verify compatibility with your master controller’s supported module list.

Package Contents

• 1 x Siemens communication module 6AR1303-0ED00-0AA0.
• Module is supplied in protective anti-static packaging.
• Documentation is available for download from Siemens website.

Our Support & Shipping Policy

• This product includes a full 12-month warranty against manufacturing defects.
• We ship worldwide using express couriers: FedEx, UPS, and DHL.
• Orders are processed quickly, with tracking provided upon dispatch.

Frequently Asked Questions

• Q: Can this module act as a PROFIBUS DP master?
• A: No, it is designed to operate as a DP slave or a communication coupler.
• Q: What is the maximum cable length for the PROFIBUS DP segment?
• A: The maximum length depends on the data rate. At 12 Mbit/s, it is 100 meters.
• Q: How do I configure the module’s IP address?
• A: You can set it via STEP 7 (TIA Portal) or using a web browser if it supports web server functionality.
• Q: Is electrical isolation provided between the PROFIBUS and Ethernet sides?
• A: Yes, the module includes integrated electrical isolation for signal protection.
• Q: I have intermittent communication faults. What should I check first?
• A: First, check the integrity of the PROFIBUS DP connectors and termination. Then, verify the network load and baud rate settings on the master.
