Schneider Electric Modbus Plus Adapter
This robust communication adapter 170PNT11020C enables reliable industrial network connections. It uses Modbus Plus protocol for efficient data transfer.
Primary Benefits
- Fast 1 Mbit/s data transmission speed
- Connects up to 31 devices in one segment
- Extended 5000 meter cable range
- Strong 8kV electromagnetic interference protection
- Clear LED status indicators for easy monitoring
- Standard SUB-D9 connector for simple wiring
- IP20 protection for indoor industrial use
Technical Specifications
- Manufacturer: Schneider Electric
- Model Number: 170PNT11020C
- Product Series: Modicon Momentum
- Communication Protocol: Modbus Plus
- Transmission Speed: 1 Mbit/s
- Network Topology: Multidrop
- Maximum Devices: 31 per segment
- Cable Length: 5000 meters maximum
- Connector Type: SUB-D9
- Protection Class: IP20
- EMI Resistance: 8 kV
- Operating Humidity: Up to 80% non-condensing
- Storage Humidity: Up to 80% non-condensing
- Maximum Altitude: 1000 meters above sea level
- Indicator Lights: LED status monitoring
Network Setup Guide
- Choose appropriate location in control cabinet
- Mount adapter securely on DIN rail
- Connect SUB-D9 cable to network port
- Wire power supply according to requirements
- Configure device addresses for each node
- Verify LED indicators show proper status
- Test communication with all connected devices
What You Receive
- Schneider Electric 170PNT11020C adapter
- Detailed installation instructions
- Mounting accessories and hardware
- Technical specification sheet
Service Information
- 12-month comprehensive warranty
- International shipping via FedEx, UPS, DHL
- Technical support available
- Replacement parts service
Technical Support Questions
- What is the maximum network expansion possible?
- Each segment supports 31 devices across 5000 meters of cable.
- How does the adapter handle electrical noise?
- 8kV EMI protection ensures stable operation in noisy environments.
- Can I use this adapter in outdoor applications?
- IP20 rating makes it suitable only for indoor, protected locations.
- What do the different LED indicators mean?
- LEDs show power, communication activity, and error status clearly.
- How many networks can one adapter support?
- Each adapter connects to one Modbus Plus network segment.
