Schneider Electric 170ADM35015 I/O Module
The 170ADM35015 is a solid-state DC I/O module from Schneider Electric. It provides reliable control for industrial automation systems with fast response times.
Product Overview
- 16 input and 16 output channels in one module
- Works with 24V DC systems commonly used in factories
- Very fast response under 0.1 ms for outputs
- Can operate in temperatures from 0 to 60°C
- 500V AC isolation protects against electrical noise
Technical Details
- Brand: Schneider Electric
- Model: 170ADM35015
- Product Line: Modicon Momentum
- Input Channels: 16 discrete DC inputs
- Output Channels: 16 solid-state outputs
- Input Voltage: 3 to 30V DC range
- Output Voltage: Up to 30V DC (24V typical)
- Input Current: ≥ 2.5 mA at State 1
- Output Current: 0.5A per point, 8A total
- Response Time: Inputs: 2.2ms/3.3ms, Outputs: <0.1ms
- Isolation: 500V AC between channels and bus
- Power Use: Maximum 8 watts
- Weight: 0.50 lbs (0.23 kg)
Key Advantages
- High-density design saves panel space
- Solid-state reliability for long service life
- Meets international IEC 1131-2 Type 1 standards
- Suitable for harsh industrial environments
- Easy integration with existing control systems
- Negative logic simplifies wiring connections
Performance Specifications
- Operating temperature: 0°C to 60°C
- Input response: 2.2 ms (on), 3.3 ms (off)
- Output response: Faster than 0.1 ms
- Electrical isolation: 500V AC protection
- Current capacity: 0.5A per output point
- Total module current: 8A maximum
Shipping & Warranty
- 12-month manufacturer warranty
- Includes one 170ADM35015 I/O module
- Protective packaging ensures safe delivery
- Worldwide shipping via FedEx, UPS, DHL
- Fast order processing within 24 hours
Expert Questions & Answers
- What does IEC 1131-2 Type 1 compliance mean?
This means the module meets global standards for industrial control equipment reliability and safety.
- How many devices can one output point control?
Each output can handle 0.5A, enough for most sensors, small relays, and indicator lights.
- What is the advantage of negative logic?
Negative logic provides better noise immunity in industrial environments with electrical interference.
- Can this module handle high-vibration applications?
Yes, solid-state construction makes it resistant to vibration and shock compared to relay-based modules.
- What’s the best way to calculate total power needs?
Add up all connected device currents and ensure the total stays below 8A for the entire module.
