Product Overview
Author: Powergear X Automation
The Schneider Electric 140NOA62200C is a high-performance Interbus master module from the Modicon Quantum series. It ensures robust operation in demanding industrial environments. The device provides reliable network communication with twisted pair cabling over distances up to 20 meters. Its compact design and standard format allow seamless integration into local racks.
Technical Specifications
- Brand: Schneider Electric
- Model: 140NOA62200C
- Product Type: Interbus master module
- Series: Modicon Quantum
- Application: Severe industrial environments
- Access Method: Master
- Communication Port: Interbus RS485 isolated 500 kbit/s, DIN 66020 compliant
- Cable Type: Twisted pair
- Maximum Cable Distance: 20 m
- Bus Current Requirement: 800 mA
- Power Dissipation: 4 W
- Rack Type: Local
- Local Signalling:
- Green LED: Active communication (ACTIVE)
- Green LED: Module run (RUN)
- Green LED: Interbus running (IS-B RUN)
- Red LED: Fault detection (F)
- Additional red LEDs: Memory, peripheral bus, processor, and remote bus faults
- Yellow LED: Bus segments shutdown
- Memory Capacity: 128 kB + 256 kB firmware EPROM, 2 kB dual-port RAM, 256 kB + 32 kB data RAM, 64 kB Interbus command EEPROM, 64 kB multi-port RAM
- Electrical Connections: 2 × SUB-D 9 connectors
- Ambient Temperature: 0–60 °C operating, -40–85 °C storage
- Humidity: 95% without condensation
- Altitude: ≤ 5000 m
- Electrostatic Discharge Resistance: 4 kV contact, 8 kV air (IEC 801-2)
- Electromagnetic Field Resistance: 10 V/m, 80–1000 MHz (IEC 801-3)
- Certifications: CE, UL, CSA
- Net Weight: 0.9 kg
Installation Guide
- Prepare local rack space for 140NOA62200C module.
- Connect twisted pair cabling to achieve maximum communication distance of 20 m.
- Ensure power supply meets 800 mA bus current requirement.
- Mount LEDs visibly for real-time status monitoring.
- Maintain ambient temperature between 0–60 °C during operation.
Packaging List
- 1 × Schneider Electric 140NOA62200C Interbus Master Module
- 1 × User Manual
- 1 × Installation Accessories Pack
- Packaging suitable for FedEx, UPS, DHL shipping
FAQ – Practical Guidance
- How do I confirm the module is running properly?
Check the green LEDs: ACTIVE, RUN, and IS-B RUN indicate normal operation. - Can it operate in extreme environments?
Yes, it supports temperatures up to 60 °C and humidity up to 95% without condensation. - How far can the communication cable reach?
The module supports twisted pair cabling up to 20 meters. - Which CPUs are compatible with this module?
Compatible with 140CPU53414B, 140CPU43412A, and 140CPU11303. - How can I detect faults quickly?
Observe red and yellow LEDs for memory, processor, or bus segment errors.
