Product details
Schneider Electric 140DDO36400C Product Snapshot
- The 140DDO36400C is a DC discrete output module for the Modicon Quantum platform.
- It supports high-density control with stable performance in demanding automation systems.
- Author: Powergear X Automation
Why Choose This Module
- 96 DC outputs reduce rack space and wiring complexity.
- Negative logic outputs ensure safe and predictable load control.
- Fast switching improves response in time-critical applications.
- Built-in protection minimizes downtime and field failures.
Electrical Output Structure
- Brand: Schneider Electric
- Series → Modicon Quantum
- Model → 140DDO36400C
- Module type → DC discrete output
- Output layout:
- Total outputs → 96 points
- Channel groups → 6 groups × 16 outputs
- Address usage → 6 output words
Voltage and Current Performance
- Nominal output voltage: 24 V DC
- Voltage operating window: 19.2 to 30 V DC
- Load current capacity:
- Per output point → ≤ 0.5 A
- Per group → ≤ 3.2 A
- Total module → ≤ 19.2 A
- Surge handling: 2 A for short-duration peaks
Speed, Accuracy, and Protection
- Response time: ≤ 0.1 ms for ON and OFF transitions
- Leakage current: Maximum 1 mA at 24 V
- Short-circuit protection: Integrated
- Overload protection: Active at module and group level
Isolation and Signal Integrity
- Channel-to-bus isolation: 500 Vrms DC for 1 minute
- Electrostatic discharge resistance:
- 4 kV contact discharge
- 8 kV air discharge
- EMI immunity: Up to 10 V/m across 80–2000 MHz
Thermal and Environmental Limits
- Operating temperature: 0 to 60 °C
- Storage temperature: −40 to +85 °C
- Humidity tolerance: 95% non-condensing
- Operating altitude: Up to 5000 meters
Mechanical and Physical Data
- Module format: Standard Quantum size
- Net weight: 0.45 kg
- Protective coating: Conformal coating Humiseal 1A33
Status Indication
- 96 green LEDs show individual output states
- Green LED indicates active bus communication
- Red LED signals detected external faults
Typical Applications
- Industrial machinery control panels
- Process automation output switching
- Distributed I/O systems in harsh environments
Packaging, Warranty, and Logistics
- Factory-sealed Schneider Electric module
- Warranty: 12 months
- Shipping via FedEx, UPS, and DHL
FAQ
- Is this module suitable for high-density output panels?
- Yes, the 96-point design reduces rack space and simplifies wiring.
- How does negative logic help in real projects?
- It improves fail-safe behavior when field power is lost.
- Can it handle inductive loads?
- Yes, it supports inductive loads when switching frequency stays within limits.
- Is EMI a concern in motor-heavy cabinets?
- The module maintains stable operation under strong electromagnetic fields.
- Does altitude affect output stability?
- Performance remains stable up to 5000 meters.
