Schneider Electric 140DAO84010C AC Discrete Output Module | Modicon Quantum

Schneider Electric 140DAO84010C Overview

• The 140DAO84010C discrete output module supports stable AC control in Modicon Quantum PLC systems.
• This module provides sixteen isolated outputs for safe and flexible load switching.
• The design targets industrial automation with high electrical stress and fast cycles.

Output Control Highlights

• Sixteen isolated AC outputs reduce interference between connected field devices.
• Output voltage range covers 20 to 132 V AC for broad application use.
• Single output word addressing simplifies PLC configuration.

Electrical Performance Details

• High dv/dt rating of 400 V/ms supports rapid signal transitions.
• Maximum voltage withstand reaches 156 V AC for 10 seconds.
• Surge current capability handles up to 30 A per point during short cycles.

Protection and Reliability

• Internal RC filter protects outputs from voltage spikes and noise.
• Associated fuse rating of 5 A improves system safety.
• Conformal coating resists moisture, dust, and corrosive environments.

Response and Load Capacity

• State change response time remains under 0.5 ms.
• Each output supports up to 4 A rms continuous current.
• Total module load current reaches 16 A rms.

Environmental Specifications

• Operating temperature range spans 0°C to 60°C.
• Storage temperature tolerance extends from -40°C to 85°C.
• Humidity resistance supports 95% non-condensing conditions.

Installation and Indicators

• Standard module format fits Modicon Quantum racks directly.
• LED indicators show bus status, faults, and individual output states.
• Bus current requirement remains stable at 350 mA.

Warranty and Shipping

• The product includes a 12-month warranty for standard industrial use.
• Shipping options include FedEx, UPS, and DHL.
• Each package contains one module with secure industrial packaging.

Professional FAQ

• Can this module handle inductive loads?
• The RC filter and surge capacity support stable inductive load switching.
• Does isolation improve system reliability?
• Isolation reduces cross-channel faults and improves long-term stability.
• How does this module perform in noisy environments?
• The dv/dt rating and coating improve resistance to electrical noise.
• Is this module suitable for high-altitude installations?
• Operation remains reliable up to 5000 meters altitude.
• Does fast response benefit motion or timing control?
• The sub-millisecond response supports precise timing applications.
