Schneider Electric 140ACI04000 Modicon Quantum Analog Input Module

Schneider Electric 140ACI04000 Analog Input Module

The 140ACI04000 is a high-performance analog input module for Modicon Quantum systems. It provides 16 channels with excellent accuracy. This module is perfect for industrial automation applications.

Technical Specifications

• Brand: Schneider Electric
• Model: 140ACI04000
• Input Channels: 16 differential
• Resolution: Up to 25,000 counts
• Accuracy: ±0.125% full scale
• Update Time: 15 ms
• Isolation: 1780V AC for 60s
• Power Consumption: 5W
• Operating Temperature: 0°C to 60°C
• Weight: 0.3 kg (0.7 lb)
• Certifications: UL 508, CSA C22.2, FM Class 1 Div 2

Installation & Support

• Easy installation in Modicon Quantum racks
• Requires 17 input words for addressing
• 12-month warranty included
• Worldwide shipping via FedEx, UPS, DHL
• Suitable for harsh industrial environments

Frequently Asked Questions

• What input signals does it support?
  It supports 0-20mA, 4-20mA, and 0-25mA signals.
• How many channels does it have?
  It provides 16 differential input channels.
• What is the resolution of this module?
  It offers up to 25,000 counts resolution.
• Does it have broken wire detection?
  Yes, for 4-20mA signals.
• What certifications does it hold?
  UL, CSA, FM Class 1 Division 2, and cUL.
