Product details
Seamless Drive Communication Module
The Allen-Bradley 1769-SM1 enables smooth communication between controllers and drives. This compact module makes automation systems work together perfectly. It is essential for modern industrial control systems.
Complete Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 1769-SM1
- Module Type: DPI/SCANport Communication Module
- Data Rates: 125 kbps or 500 kbps
- Power Consumption: 280 mA at 5V DC
- Channel Consumption: 60 mA at 12V DC
- Operating Temperature: -10°C to 50°C (14°F to 122°F)
- Max Cable Length: 10m to 100m (depending on data rate)
- Weight: 2 lbs (0.9 kg)
- Dimensions: 8 x 8 x 5 inches
- Wire Size: 22-14 AWG (solid), 22-16 AWG (stranded)
- Compatibility: PowerFlex 7-Class drives, DPI devices, SCANport products
Package & Shipping Info
- One 1769-SM1 communication module
- 12-month warranty
- Worldwide shipping via FedEx, UPS, DHL
- International shipping available
Technical Questions Answered
- What controllers work with this module?
Works with MicroLogix 1500 and CompactLogix controllers. - What is the maximum data transfer rate?
Supports up to 500 kilobits per second. - Can I use this with newer PowerFlex drives?
Designed for PowerFlex 7-Class drives specifically. - What is the maximum cable length?
Up to 100 meters at lower data rates. - Does this require special programming?
Auto-detection and auto-bauding make setup simple.
