Allen-Bradley 1766-L32BWAA MicroLogix 1400 Controller
The Allen-Bradley 1766-L32BWAA delivers powerful control in a compact package. This MicroLogix 1400 controller offers excellent connectivity and flexible I/O options. Rockwell Automation designed it for reliable industrial performance.
Technical Specifications
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1766-L32BWAA
- Input Power: 100-240V AC, 47-63 Hz
- Digital Inputs: 12 Fast 24V DC, 8 Normal 24V DC
- Digital Outputs: 12 Relay (2A @ 240V AC)
- Analog Inputs: 4 channels, 0-10V DC, 12-bit resolution
- Analog Outputs: 2 channels, 0-10V DC, 12-bit resolution
- Memory: 20 KB (10 KB program, 10 KB data)
- Communication Ports: Ethernet, RS-232, RS-232/485 combo
- Protocol Support: EtherNet/IP, Modbus TCP/IP, DF1, DH-485, ASCII
- Operating Temperature: 0°C to 55°C (32°F to 131°F)
- Dimensions: 3.5 x 7.08 x 3.43 inches (89 x 180 x 87 mm)
- Weight: 2 lbs (0.9 kg)
Packaging List
- One Allen-Bradley 1766-L32BWAA Controller Unit
- Mounting hardware and installation guide
- We ship via FedEx, UPS, or DHL for reliable delivery
Frequently Asked Questions
- What expansion modules work with this controller?
You can add up to seven 1762 series expansion I/O modules. - Can I use this controller for motion control applications?
It supports up to six 100 kHz high-speed counters for basic motion tasks. - How do I program this MicroLogix 1400 controller?
Use Rockwell’s RSLogix Micro software for programming and configuration. - Does the controller include battery backup?
Yes, it features battery-backed RAM for program retention during power loss. - What industrial protocols does the Ethernet port support?
It supports EtherNet/IP, Modbus TCP/IP, and DNP3 over Ethernet.
