Rockwell Automation 1762-L24BXBR PLC – MicroLogix Controller

Allen-Bradley 1762-L24BXBR MicroLogix 1200 Programmable Controller

The Allen-Bradley 1762-L24BXBR is a compact and powerful PLC from Rockwell Automation’s MicroLogix 1200 series. It delivers robust performance in a small footprint, ideal for space-conscious control panels. This versatile controller offers a mix of I/O and flexible communication options.

Detailed Technical Specifications

• Brand: Allen-Bradley / Rockwell Automation
• Model: 1762-L24BXBR (Full Catalog Number: 1762-L24BXBR)
• Power Supply: 24V DC Input
• Inputs: 10 x 24V DC (Sink/Source); 4 x Fast 24V DC
• Outputs: 5 x Relay (2A); 4 x 24V DC FET (0.5A); 1 x High-Speed 24V DC FET
• Relay Contact Rating: 24-125V DC / 120-240V AC
• Communication Ports: Two (2) x 8-pin mini-DIN (Programming & Primary)
• Protocols: DF1, DH-485, ASCII, MODBUS
• Operating Temperature: 0 to 55 °C (32 to 131 °F)
• Dimensions (HxWxD): 90 x 160 x 87 mm (3.5 x 6.3 x 3.4 in)
• Shipping Weight: 2.4 lbs (1.1 kg)

Packaging List

• One (1) Allen-Bradley 1762-L24BXBR MicroLogix 1200 Controller Unit.
• Required mounting hardware and quick start guide.
• We ship all orders via reliable couriers: FedEx, UPS, or DHL.

Frequently Asked Questions (FAQ)

• What is the input frequency range?
  Inputs 0-3 accept 0-20 kHz; other inputs handle 0-1 kHz.
• Can I add more I/O points to this system?
  Yes, you can expand it with up to six additional 1762 expansion modules.
• Does this PLC have a real-time clock?
  Yes, it includes an integrated real-time clock for time-based logging and control.
