Allen-Bradley 1734-AENT Ethernet/IP Communication Adapter

The Allen-Bradley 1734-AENT makes your POINT I/O system part of your Ethernet/IP network. This powerful adapter lets your controller talk to many I/O modules at once.

Technical Specifications

• Brand: Allen-Bradley
• Manufacturer: Rockwell Automation
• Full Model Number: 1734-AENT
• Series: POINT I/O
• Product Type: Communication Adapter
• Input Voltage: 24 Volts DC
• Ethernet Ports: 1 RJ-45 (Category 5)
• Max I/O Modules: 63
• Max I/O Points: 504
• POINTBus Current: 1000 milliamps
• Power Consumption: 10.4 Watts
• Communication Rate: 10/100 Mbits/s
• Inrush Current: 6 Amps
• Operating Temperature: -20°C to 55°C
• Mounting: DIN rail

Installation & Setup

• Connect the 1734-AENT to your DIN rail quickly.
• Use a standard Category 5 Ethernet cable for network connection.
• Assign an IP address easily using BootP or DHCP tools.
• This adapter provides power for up to 17 modules on the bus.
• The module includes reverse polarity protection for safety.

Packaging & Shipping

• Your order includes one 1734-AENT Ethernet/IP Adapter.
• We pack all items carefully to prevent shipping damage.
• We ship worldwide using FedEx, UPS, and DHL.

Frequently Asked Questions (FAQ)

• Q: How many devices can this adapter connect?
  A: The 1734-AENT can support up to 63 I/O modules total.
• Q: What type of network cables should I use?
  A: You should use Category 5 Ethernet cables for best results.
• Q: Can multiple controllers use this adapter?
  A: Yes, several controllers can connect to the 1734-AENT at once.
• Q: What is the operating voltage range?
  A: It operates with a wide voltage range from 10 to 28.8V DC.
• Q: Does it support auto-negotiation for speed?
  A: Yes, it auto-negotiates between 10 and 100 Mbits/s automatically.
