Rockwell Automation 1734-8CFG Module – POINT I/O Series

Allen-Bradley 1734-8CFG DC Configurable I/O Module

The Allen-Bradley 1734-8CFG is a versatile 8-point DC configurable I/O module from the renowned POINT I/O series by Rockwell Automation. It offers exceptional flexibility by auto-configuring its points as inputs or outputs, making it a perfect fit for dynamic industrial automation environments.

Detailed Technical Specifications

• Brand: Allen-Bradley
• Manufacturer: Rockwell Automation
• Full Model Number: 1734-8CFG
• Series: POINT I/O
• Module Type: DC Configurable I/O Module
• Number of Points: 8 Inputs/Outputs
• Input Voltage (Min): 11 V DC
• On-state Input Current: 2-5 mA
• On-state Output Voltage: 10 to 28.8 V DC
• Power Dissipation: 2.6 W
• POINTBus Current: 100 mA at 5V DC
• Operating Temperature: -20°C to 55°C
• Enclosure: Open
• Mounting: DIN rail

Installation & Compatibility Guide

• Install the 1734-8CFG module with ease before or after the base is mounted.
• Uses a keying switch position value of 1 for physical prevention of incorrect installation.
• Ensure compatibility by using only these base units: 1734-TOPS, 1734-TOP, 1734-TBS, and 1734-TB.
• All connected I/O must use a PELV or SELV compliant power source for safety.

Frequently Asked Questions (FAQ)

• Q: Can I change an I/O point from input to output remotely?
  A: Yes, the 1734-8CFG points can be configured remotely over the network.
• Q: Is this module suitable for harsh environments?
  A: With an operating temperature range of -20°C to 55°C, it handles most industrial settings.
• Q: What does the configurable input filter do?
  A: You can independently set each input’s filter in milliseconds to reject signal noise.
