Rockwell 1756-TIME ControlLogix Time Synchronization Module

Product Description

The Allen-Bradley 1756-TIME is a ControlLogix time synchronization module.
It provides precise GPS-based time across automation networks.
This module supports Ethernet, IRIG-B, and antenna interfaces.
It ensures accurate time for reporting, events, and diagnostics.
It installs in any ControlLogix chassis slot and uses Studio 5000 for setup.
Users configure the initial IP address via BOOTP/DHCP server.

Technical Data

• Brand: Allen-Bradley / Rockwell Automation
• Model: 1756-TIME
• Series: ControlLogix
• Module Type: Time Synchronization Module
• Technology: Global Positioning System (GPS)
• Clamp Type: Spring-Clamp
• Status Indicators: PPS, SYNC, OK
• Communication Ports: Ethernet, IRIG-B, Antenna
• Backplane Current: 1.2A @ 5V, 2.5mA @ 24V
• Power Dissipation: 6.19W max
• Voltage Rating: 1.01A @ 5.1V DC, 2.64mA @ 1.2V DC
• Isolation Voltage: 30V continuous, tested 1000V AC 60s
• Wire Size: 20 AWG
• Dimensions: 5.51 x 4.41 x 5.71 in
• Weight: 0.3 lb (0.1 kg)
• Operating Temperature: 32–140°F (0–60°C)
• Enclosure: Open type, slot width

Package Contents

• 1x Allen-Bradley 1756-TIME Module
• User manual (downloadable)
• 12-month warranty card

Shipping

• Worldwide fast delivery
• Carriers: FedEx, UPS, DHL

Diagnostics

• PPS LED: Flashes every second for sync check
• SYNC LED: Shows lock to time source
• OK LED: Module status and health

FAQ

• Q: Does it need external power?
  A: No, it is powered by ControlLogix backplane.
• Q: Can it serve as master clock?
  A: Yes, supports master and slave roles.
• Q: Which software is required?
  A: Studio 5000 Logix Designer.
• Q: Is antenna included?
  A: Antenna sold separately.
