Product details
E84AVSCE3024SBS | Lenze Inverter 8400 StateLine
The Lenze E84AVSCE3024SBS from the 8400 StateLine series is a high-efficiency inverter designed for smooth motion and energy-saving performance.
Built by Powergear X Automation, this compact “Slim” version combines safety, precision, and connectivity for modern industrial control.
Key Specifications
- Model: E84AVSCE3024SBS
- Series: 8400 StateLine C
- Power Rating: 3 kW
- Voltage: 400/500 V (3-phase, PE AC)
- Control Type: Vector-controlled inverter
- Version: Slim design with STO safety system
- Weight: 7 kg
Performance Highlights
- High precision speed and torque control
- Energy-saving “VFC eco” function
- Built-in brake management for controlled stops
- Integrated “Safe Torque Off (STO)” safety system
- Supports simple and advanced motion control
Connectivity & Communication
- Digital I/O: 5x inputs, 1x output
- Analog I/O: 1x input, 1x output
- Relay Output: 1x NO/NC
- Fieldbus Support: CANopen, EtherCAT, EtherNet/IP, POWERLINK, PROFIBUS, PROFINET
- DC Bus: Included (400V type)
Environmental Conditions
- Operating Range: -10°C to +40°C
- Protection: Standard industrial (IE33 per IEC 60721-3-3)
- Cooling: Natural or forced air depending on setup
Applications
- Conveying and material handling systems
- Palletizers and lifting systems
- Extruders in plastics industry
- Filling and packaging systems
- Automation processes with feedback control
Warranty & Shipping
Advanced Technical Advantages
- Compact and slim housing for small control cabinets
- Reliable thermal management and protection circuits
- Flexible communication with major industrial networks
- Supports regenerative energy feedback
- Fully compliant with Ecodesign Directive EN IEC 61800-9-2
Professional FAQ
- Q: Can this inverter handle high inertia loads?
A: Yes, the vector control mode maintains torque stability for high inertia systems. - Q: Is it possible to use this inverter without a feedback encoder?
A: Yes, it supports both open-loop and closed-loop speed control. - Q: How can I enable the STO safety function?
A: The STO terminals are clearly labeled; contact
sales@powergearx.com
for wiring documentation. - Q: Does it support EtherNet/IP and PROFIBUS at the same time?
A: Only one communication protocol can be active at once; configuration is set via software. - Q: How do I choose the right braking resistor?
A: Consult our team via WhatsApp
+86 18030005825
for recommended resistor ratings.
Contact Information
- Manufacturer: Lenze
- Authorized Supplier: Powergear X Automation
- Email: sales@powergearx.com
- WhatsApp: +86 18030005825
