Product details
Bently Nevada 3300 XL 8 mm Probe: Model 330101-00-44-10-02-CN
Key Identifier: 330101-00-44-10-02-CN
Industrial-grade vibration sensor with 3/8-24 UNF thread and 8 mm PPS probe tip. Features patented CableLoc technology (330 N pull strength) and optional FluidLoc leak-proof cable for oil-rich environments.
Suffix Configuration
| 00 | 0.0 in unthreaded length |
| 44 | 4.4 in case length |
| 10 | 1.0 m (3.3 ft) total cable |
| 02 | Standard ClickLoc connector |
| CN | China-specific certifications |
Technical Specifications
| Brand | Bently Nevada |
| DC Resistance | 7.59Ω ±0.50 @1.0m |
| Temperature Range | -62°F to +500°F (cable/connector) |
| Linear Range | 0.25–2.3 mm (10–90 mils) |
| Accuracy | ±0.025mm linear deviation |
| Case Material | AISI 303/304 stainless steel |
Key Features
- Rugged Design: 8mm PPS tip with enhanced mechanical protection
- Humidity Stability: <3% ASF drift @93% RH for 56 days (IEC 68-2-3)
- Field Wiring: Supports 305m shielded triad cables
- Pressure Seal: Viton O-ring (custom testing available)
Contact: For technical inquiries: sales@ubestplc.com
For more detailed information: 3300 XL 8 mm Proximity Transducer System Datasheet
