PR6423 Eddy Current Displacement Sensor
Powergear X presents the PR6423/010-020 8mm non-contact sensor. This precision instrument measures dynamic shaft displacement in critical machinery. It delivers reliable performance in demanding industrial environments.
Key Technical Specifications
- Brand: Emerson EPRO
- Model: PR6423/010-020
- Linear Range: 2 mm (80 mils)
- Sensitivity (ISF): 8 V/mm (203.2 mV/mil)
- Non-Linearity: ±0.025 mm (±1 mil)
- Initial Gap: 0.5 mm (20 mils)
- Min Shaft Size: 25 mm (0.79″)
- Target Material: 42CrMo4 Steel
Environmental Durability
- IP Rating: IP66 (Dust and water resistant)
- Temp Range: -35°C to +180°C
- Sensor Tip: PEEK Material
- Case: Stainless Steel Construction
- Cable: PTFE with Armored Protection
Safety Certifications
- Intrinsic Safety: ATEX/IECEx/CSA (ia)
- Non-Sparking: ATEX/IECEx/CSA (nA)
- Temperature Class: T3, T4, T6 Available
- Compliance: CE, UL, ANSI Standards
Model Variants Guide
- PR6423/010-020 (Standard)
- Tip Diameter: 8mm
- Case Thread: M10x1
- Armored Cable: Yes
- PR6423/01A-BCD (Configurable)
- Case Length Options Available
- Cable Lengths: 1m to 4m
- Connector Types: Lemo Standard
Shipping & Packaging
- Complete PR6423 sensor unit
- Specified cable length pre-attached
- Protective industrial packaging
- Global shipping via FedEx, UPS, DHL
Installation Requirements
- Minimum shaft diameter: 25mm
- Ferromagnetic steel target material
- Initial gap setting: 0.5mm from shaft
- M10x1 mounting thread provided
Frequently Asked Questions
- What is the measurement range?
- The sensor offers 2mm linear range
- Can it handle high temperatures?
- Yes, it operates up to 180°C
- What connectors are available?
- Lemo connectors are standard
- Is it explosion-proof?
- Yes, with intrinsic safety certifications
