Allen-Bradley 25B-A2P5N114 PowerFlex 525 Drive: Precision Motor Control Solution

Control your 0.5 HP motors efficiently with the Allen-Bradley 25B-A2P5N114. Converts 1-phase power to 3-phase output. Features built-in diagnostics and easy DIN rail mounting.

Technical Specifications

• Brand: Allen-Bradley
• Model: PowerFlex 525
• Full Part Number: 25B-A2P5N114
• Output Current: 2.5A
• Frequency Response: 0-599 Hz
• Resolution: 10-bit analog output
• Temperature Range: 0°C to 40°C
• Environmental Rating: IP20
• Anti-Interference: EMI filtered
• Certifications: EN61800-3, CE

Installation Guide

• Maintain minimum clearance around unit for airflow
• DIN rail mount compatible
• Integrated Rs485/DSI communications

Operation & Diagnostics

• Control Modes:
  • Sensorless vector control
  • Closed-loop velocity
  • V/Hz control
• I/O Ports:
  • 7 digital inputs (6 programmable)
  • 2 analog inputs
  • 2 relay + 2 opto outputs
• Diagnostics: Real-time fault logging via Ethernet

Compatibility & Applications

• Works With: Pumps, fans, conveyors, HVAC systems
• Communication: EtherNet/IP, DSI, Modbus

Packaging & Support

• Includes: Drive unit, installation guide
• Warranty: 12 months
• Shipping: FedEx, UPS, DHL

FAQ

• Q: Can it run a 3-phase motor from 1-phase power?
  A: Yes! Converts 1-phase 240V input to 3-phase output
• Q: Does it include overload protection?
  A: Yes, removable MOV protects against ground faults
