Allen-Bradley 22D-E1P7H204: Space-Smart Motor Control
Compact Power for Demanding Applications
Control motors precisely with the 22D-E1P7H204. This 1HP drive fits tight spaces and cuts energy costs.
Key Advantages
- Ultra-quiet 16kHz PWM operation
- 75% smaller enclosure with plate mounting
- Zero stacking up to 40°C (104°F)
- Sensorless vector control for high torque
- DIN rail or panel mount options
Technical Specifications
Brand: Allen-Bradley
Model: 22D-E1P7H204
Power Details:
– Input: 600V AC 3-phase (540-650V range)
– Output: 1 HP (0.75 kW), 1.7A
– Frequency: 0-500 Hz adjustable
Physical Design:
– Frame Size: B (Compact)
– Mount: Plate or DIN rail
– Weight: 1.8 kg (4 lbs)
Environmental Ratings:
– Operating Temp: -10°C to 50°C (14°F to 122°F)
– Humidity: 0-95% non-condensing
– Altitude: Up to 1000m (3280 ft)
Smart Control Features
- 4-digit display with 10 status LEDs
- StepLogic programming wizards
- Offline/online parameter editing
- NEMA 4X keypad compatibility
- Motor thermal protection
Shipping & Warranty
12-month manufacturer warranty. Global delivery via:
- FedEx Express
- UPS Worldwide
- DHL Priority
Professional FAQs
Q: Maximum PWM frequency?
A: 16 kHz for silent operation
Q: EMC compliance options?
A: External filters available for Class A/EN55011
Q: Keypad options included?
A: Compatible with NEMA Type 1 and 4X keypads
Q: DIN rail mounting possible?
A: Yes – clips included
Q: Program without power?
A: Yes – offline programming supported
