K-LB-1.6G: Low-Voltage Surge Protection for Sensitive Instruments
Critical Protection Features
- 20kA surge protection (8/20µs)
- Ultra-low 6V rated voltage for sensitive devices
- Auto-reset functionality
- DIN rail mounting (EN 60715)
- ≤12V on-state voltage
Technical Specifications
- Model: K-LB-1.6G
- Channels: 1
- Max Voltage: 6V DC
- Surge Current: 20kA (8/20µs)
- Response Time: 1 ns (symmetrical)
- Leakage Current: ≤5 µA
- Temp Range: -30°C to +80°C (-22°F to 176°F)
- Series Resistance: ≤0.3Ω per conductor
- Bandwidth: ≥40 kHz
Industrial Applications
- Laboratory precision instruments
- Medical diagnostic equipment
- Low-voltage sensor networks
- Battery monitoring systems
- Renewable energy controllers
- IoT device protection
Installation Requirements
- Must connect to certified earth ground
- 35mm DIN rail mounting
- Terminal connections: 1-2 (unprotected), 7-8 (protected)
- Same potential as protected instruments
Package Contents
- K-LB-1.6G Surge Barrier
- DIN rail clips
- 12-month warranty
Global Shipping
FedEx | UPS | DHL – International Delivery
FAQ
Q: Suitable for 4-20mA sensors?
A: Designed for ultra-low voltage devices (<6V)
Q: Medical equipment compatibility?
A> Yes, ideal for sensitive medical instruments
Q: Response time during surge?
A> 1 nanosecond symmetrical response
Q: Can I use in Zone 0 areas?
A> Certified for Zone 1/Division 1
Q: Maximum wire size?
A> 2.5mm² per terminal
