MTL5025 Intrinsic Safety Barrier | Zone 0 Certified Fast Delivery

MTL5025 Intrinsic Safety Barrier: Reliable Hazardous Area Control for Switches & LEDs

Product Description

Control hazardous-area devices safely! The MTL5025 barrier lets you operate on/off equipment in Zone 0/Div.1 locations using safe-area switches. Works with intrinsically safe loads and simple devices like LEDs.

Technical Specifications

• Brand/Model: MTL5025 Standard Series
• Input Voltage: 20-35V DC
• Output Current: 45mA max
• Output Voltage: 8.6V-24V
• Power Consumption: 90mA@24V
• Temperature Range: -20°C to +60°C
• Safety Ratings:
  • ATEX/IECEx Zone 0, IIC, T4-T6
  • UL Division 1, Group A
  • Um = 250V AC/DC
• Terminal Functions:
  • 1: Output (–) | 2: Output (+)
  • 3: Earth leakage | 11: Supply (–)
  • 12: Supply (+)

Compatibility

• Certified IS low-power loads
• Non-storing simple apparatus (LEDs)
• Switch controls from safe areas

Packaging & Support

• Warranty: 12 months
• Shipping: FedEx, UPS, DHL
• Contents: Barrier unit, datasheet

Frequently Asked Questions

• Q: Can this drive solenoids?
  A: Only certified IS loads under 45mA
• Q: Is external grounding needed?
  A: Use Terminal 3 for earth leakage detection
• Q: Temperature limits?
  A: Standard range: -20°C to +60°C
