MTL3045 Current Isolator: Precision Hazardous Area Driver

Technical Specifications

• Brand: MTL
• Model: MTL3045
• Signal Performance:
  • Input: 0-20mA or 4-20mA
  • Accuracy: ±0.1% full scale
  • Temp drift: <0.005%/°C
  • Response: 55ms typical
• Power & Load:
  • Supply: 20-35V DC
  • Current: 90mA max
  • Load capacity: 800Ω
  • Ripple: <40μA p-p
• Safety Ratings:
  • Zone 0, IIC, T4-T6 certified
  • Div 1, Group A compliant
  • Isolation: 250V AC

Terminal Configuration

• Input +: Connect controller signal
• Input -: Controller return
• Output +: Device power
• Output -: Device return
• Supply +: 20-35V DC
• Supply -: Power common

Key Advantages

• Replaceable 125mA fuse protection
• 150g compact DIN-rail design
• 0.05% linearity error
• Works with MTL3046B for cross-hazard transfer
• FM-approved safety parameters

Package & Support

• 12-month warranty
• Global shipping: FedEx, UPS, DHL
• Includes DIN rail mount
• Fuse replacement kit

Technical FAQs

• Q: Minimum operating voltage?
  A: 20V DC required
• Q: Surge protection rating?
  A: 1.5kV line-to-line
• Q: Humidity tolerance range?
  A: 5-95% non-condensing
• Q: Vibration resistance?
  A: 5g @ 10-150Hz
• Q: Calibration interval?
  A: 3-year recommended cycle
