MR-J4W2-1010B Mitsubishi Dual-Axis Servo | 1kW MELSERVO MR-J4 | SSCNET III/H

MR-J4W2-1010B Dual-Axis Servo Amplifier – Save Space, Control Two Motors

The Mitsubishi MR-J4W2-1010B controls two axes with one unit. It belongs to the MELSERVO MR-J4 series. This drive works with 1‑phase or 3‑phase power (200‑230 VAC). It uses SSCNET III/H for fast communication. Built-in dynamic and regenerative brakes improve safety. Compact size (85mm wide) fits tight panels. Ideal for multi‑axis machines.

Technical Specifications

• Brand & Model
  • Manufacturer: Mitsubishi
  • Product Line: MELSERVO MR-J4
  • Part Number: MR-J4W2-1010B
  • Number of Axes: 2 axes
• Power & Voltage
  • Output Power Rating: 1 kW (per axis)
  • Current Rating: 6 A
  • Rated Supply Voltage: 200‑230 VAC (1‑phase or 3‑phase)
  • Permissible Voltage Fluctuation: 170‑264 VAC
  • Current Consumption: 9.8 A
  • Power Consumption: 55 W
• Interface & I/O
  • Command Interface: SSCNET III/H
  • Digital Inputs: 6
  • Digital Outputs: 4
• Braking & Protection
  • Braking Unit: Built‑in dynamic brake + regenerative brake
  • Protection Class: IP20
• Physical & Cooling
  • Dimensions (HxWxD): 168 mm x 85 mm x 195 mm
  • Weight: 1.36 kg (3.00 lbs)
  • Cooling Method: Forced ventilation
  • Control Method: Sine wave PWM + current control

Installation Guide

• Mounting
  • Place vertically on a metal plate.
  • Leave 50mm free space above and below.
• Wiring
  • Use twisted pair cables for SSCNET III/H.
  • Separate power lines from signal lines.
• Grounding
  • Connect to class 3 ground (100Ω max).
• Cooling
  • Ensure forced ventilation is not blocked.

Debugging & Maintenance

• Software setup
  • Use MR Configurator2 via USB (same as MR-J4 series).
• Auto‑tuning
  • One click for each axis. Saves time.
• Alarm log
  • Stores last 20 errors per axis.
• LED indicators
  • Show status for both axes.

Compatibility

• Servo motors
  • Mitsubishi HG-KR, HG-MR, HG-SR series (1kW or less per axis).
• Controllers
  • Mitsubishi Q172D, Q173D, or any SSCNET III/H master.
• Cables
  • MR-J3BUS for SSCNET III/H daisy chain.

Package Contents

• 1 x MR-J4W2-1010B Servo Amplifier
• 1 x Built‑in dynamic brake & regenerative brake
• 1 x Quick start guide (English)
• 1 x Safety manual
• 2 x CN1 connectors (for axis 1 and 2)
• Power cables not included.

Warranty & Shipping

• 12‑month warranty
  • Covers factory defects. From invoice date.
• 12‑24 hour dispatch
  • For in‑stock units (business days).
• Express couriers
  • FedEx, UPS, DHL – tracking included worldwide.

Expert Review – Motion Control Specialist

The MR-J4W2-1010B cuts panel space by half. One drive runs two motors. The built‑in dynamic and regenerative brakes handle deceleration without extra parts. SSCNET III/H offers fast, real‑time control. At 1kW per axis, it suits many factory machines. For OEMs building multi‑axis systems, this drive lowers cost and wiring time. Highly recommended for pick‑and‑place or small CNC.

Manager’s Insight – Powergear X Automation

We see strong demand for the MR-J4W2-1010B. It simplifies dual‑axis builds. The 12‑month warranty and 12‑24h shipping via FedEx/UPS/DHL give our customers confidence. The regenerative brake saves energy. IP20 protection keeps dust out. For packaging, labeling, or assembly lines, this is a smart, compact choice.

Applicable Devices & Applications

• Pick‑and‑place machines – control X and Z axes together.
• Small CNC routers – drive two axes with one unit.
• Packaging equipment – feeder and cutter axes.
• Labeling machines – conveyor and label head.
• Assembly robots – dual‑arm or dual‑station.
• Printing presses – two synchronized rollers.

Frequently Asked Questions (FAQ)

• How many motors can MR-J4W2-1010B control?
  • Two motors. Each axis provides 1kW output.
• Does it work with 1‑phase power?
  • Yes. Use 1‑phase 200‑230 VAC or 3‑phase.
• What is SSCNET III/H?
  • A high‑speed motion network from Mitsubishi.
• Are both brakes built‑in?
  • Yes. Dynamic brake and regenerative brake are inside.
• What warranty and shipping do you offer?
  • 12 months. We ship within 12‑24 hours via FedEx, UPS, or DHL.

Selection Guide & Buying Tips

• Axis count
  • Need two axes? This unit saves space and cost vs two single drives.
• Power per axis
  • Each axis max 1kW. For higher power, see MR-J4W2-2020B.
• Braking needs
  • Built‑in regenerative brake handles most deceleration. No external resistor.
• Communication
  • Must use SSCNET III/H. Not for pulse‑train or RS‑422.
• Cooling
  • Forced ventilation required. Keep fans clean.

Experienced User Advice

• Wiring order
  • Connect SSCNET III/H cables in a daisy chain. Terminate at last drive.
• Brake test
  • Test dynamic brake with emergency stop. It stops motors fast.
• Parameter backup
  • Save parameters for both axes separately using MR Configurator2.
• Heat management
  • Leave 100mm above fan outlet for hot air.
