Schneider Electric 140AII33010 Intrinsically Safe Analog Input Module
The 140AII33010 is a specialized 8-channel analog input module from Schneider Electric. It is designed for use in hazardous environments where intrinsic safety is required. This module connects seamlessly with Modicon Quantum automation systems.
Technical Specifications
- Brand & Model: Schneider Electric 140AII33010
- Input Channels: 8 isolated channels
- Input Ranges: 0-20 mA, 4-20 mA, 0-25 mA
- Resolution: Up to 25,000 counts (0-25 mA range)
- Accuracy: ±0.05% typical at 25°C (77°F)
- Update Time: 750 ms for all channels
- Input Impedance: 100 Ω ±0.1%
- Isolation: 2500 V DC between channels and bus
- Power Consumption: 1500 mA from backplane
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Safety Certifications: ATEX, IECEx, CSA, UL
- Weight: 0.3 kg (0.7 lb)
- Warranty: 12 Months
- Shipping: FedEx, UPS, DHL
Installation & Safety Information
- Designed for use with Modicon Quantum PLC systems
- Must be used with approved intrinsic safety barriers
- Operating altitude up to 5000 meters (16404 feet)
- Requires 95% relative humidity (non-condensing)
- Do not attempt hot swapping – power down system first
- Use only in environments classified as Zone 20, 21, or 22
Frequently Asked Questions
- Q: What makes this module “intrinsically safe”?
A: It is designed to prevent sparking and limit thermal energy. This prevents ignition in flammable atmospheres. - Q: Can I use this module with standard sensors?
A: Yes, but you must use approved intrinsic safety barriers between the module and field devices. - Q: What PLC systems is this module compatible with?
A: It works with Modicon Quantum systems using Unity Pro, Concept, or ProWORX software. - Q: How does the broken wire detection work?
A: For 4-20 mA signals, the module detects when current drops below 4 mA and signals a fault. - Q: Can I use this module in non-hazardous areas?
A: Yes, but its special safety features make it more expensive than standard input modules.
