Bently Nevada 330904-08-15-10-12-05 Proximity Probe
Product Overview
The Bently Nevada 330904-08-15-10-12-05 is a 3300 NSv proximity probe with M8x1 thread and armored cable. It offers stable performance in high-temperature, corrosive, or high-vibration environments, making it ideal for compact process compressor installations.
Key Technical Specifications
- Measurement Range: 0.25 to 1.75 mm (10 to 70 mils)
- Linear Range: 1.5 mm (60 mils)
- Accuracy: ±2.3 mils from straight line (DSL)
- Output Signal: -1 to -13 VDC
- Recommended Gap: 1.0 mm (40 mils)
- Scale Factor: 7.87 V/mm (200 mV/mil) ±20%
- Frequency Response: 0 to 10 kHz
- Operating Temperature: -52°C to +177°C
- Cable Type: 75 Ω coaxial with Fluoroethylene Propylene (FEP) insulation
- Connector Type: Miniature coaxial ClickLoc
Compatibility
- Compatible with 3300 RAM probes and extension cables
- Compatible with 3300 XL NSv Proximitor sensors
- Interchangeable with legacy 190 series probes with improved accuracy and resistance
Installation Guide
- Thread Size: M8x1
- Max Thread Engagement: 12 mm
- Recommended Torque: 5.1 N·m (45 in·lb)
- Max Torque: 7.3 N·m (65 in·lb)
- Minimum Bend Radius: 25.4 mm
- Field Wiring: 16–24 AWG (with ferrules: 18–23 AWG)
Packaging and Warranty
- Condition: New & Original
- Packaging: Factory Sealed
- Warranty: 12 Months
- Shipping: FedEx, UPS, DHL available
- Includes: Probe, armored cable with ClickLoc connector (no certificate)
Model Tree Structure
- Model: 330904 – 3300 NSv Probe
- Thread Type: – M8X1
- Unthreaded Length: -08 – 80 mm
- Overall Case Length: -15 – 150 mm
- Total Cable Length: -10 – 1.0 meter
- Connector Type: -12 – Mini ClickLoc
- Approval Option: -05 – Multiple Approvals
