Product details
Meggitt Vibro-Meter 913-402-000-012/A2-E045-F0-G00 Proximity Measuring System
- Manufacturer: Meggitt (Vibro-Meter)
- Product No.: 913-402-000-012/A2-E045-F0-G00
- Product Type: Proximity Measuring System
- Made in: Switzerland
- Warranty: 12 Months
- Shipping: FedEx, UPS, DHL
Suffix Details:
- A2: Ex i explosion-proof environment
- E045: Extension cable 4.5 m ± 450 mm
- F0: No cable or connector protection
- G00: No flexible hose
Technical Highlights:
- Weight: 0.22 kg
- Input Power: From IQS900 signal conditioner
- Operating Temperature: −40°C to +180°C (drift <5%)
- Short-Term Survival: +220°C
- Explosion Zone Rating: −40°C to +195°C
- Protection Class: IP68 (probe head)
- Vibration Resistance: 5 g peak (10–500 Hz)
- Shock Resistance: 15 g peak (11 ms half sine-wave)
Construction:
- Coil Diameter: Ø8 mm, wire coil
- Tip Material: Torlon (polyamide-imide)
- Body Material: Stainless Steel (AISI 316L)
- Cable Type: FEP-covered 70 Ω coaxial, Ø3.6 mm
- Connector: Self-locking miniature coaxial
Optional Protection:
- Stainless steel flexible hose: mechanical protection
- FEP sheath: high chemical resistance, flexible and low friction
Key Selling Points:
- Certified Ex i explosion-proof design
- Wide temperature range up to +220°C
- Rugged stainless-steel housing for harsh conditions
- Reliable FEP-insulated coaxial cable
- Simple installation and long service life
Contact Information:
- Email: sales@powergearx.com
- WhatsApp: +86 18030005825
FAQ
- What is the temperature limit of the 913-402-000-012 sensor?
- It operates from −40°C to +180°C and can survive up to +220°C short-term.
- Is the sensor suitable for explosive areas?
- Yes, it is Ex i certified for explosive zones.
- Can I add a protective hose to this model?
- Yes, a stainless steel hose can be added for mechanical protection.
- What type of connector is used?
- It uses a self-locking miniature coaxial connector for secure fit.
- Does Powergear X offer warranty support?
- Yes, this product includes a 12-month factory warranty.
