Leuze K-D M12A-3P-5m-PVC Industrial Connection Cable | Durable 5m PVC M12 Plug

Leuze K-D M12A-3P-5m-PVC Connection Cable Overview

• The Leuze K-D M12A-3P-5m-PVC is a durable 3-pin M12 axial cable.
• Designed for reliable signal and power transmission in industrial automation.
• Features strong PVC sheath and nickel-plated screw connector for secure connection.
• Ideal for sensors, field devices, and control systems.

Type Code Structure

• K-D: Connection cable with connector
• M12A: M12 connector, A-coded
• 3P: 3 pins
• 5m: Cable length 5 meters
• PVC: Cable sheath material PVC

Technical Specifications

• Manufacturer: Leuze Electronic
• Model: K-D M12A-3P-5m-PVC
• Connector Type: M12 axial, 3-pin
• Operating Voltage: ≤250 VAC/DC
• Rated Current: ≤4A per contact
• Insulation Grade: Category I (IEC 60664-1)
• Conductor Cross-section: 0.34 mm²
• Sheath Diameter: 4.7 – 5.7 mm
• Bending Radius: ≥10 × sheath diameter
• Operating Temperature (fixed): -30°C to +70°C
• Operating Temperature (flexible): -5°C to +70°C
• Housing: Diecast zinc, nickel-plated, screw fit, 0.6 Nm torque

Key Features & Benefits

• Strong PVC jacket resists oil, vibration, and bending stress.
• Nickel-plated metal lock ensures long-term contact stability.
• Supports both AC and DC circuits up to 250V.
• Compact design fits tight industrial spaces.
• Excellent electrical insulation performance.
• 12-month quality warranty for worry-free use.

Shipping & Warranty

• All products come with a 12-month warranty.
• Fast and secure delivery via FedEx, UPS, or DHL.
• Each cable is factory-tested before shipment.

FAQ

• Q:Is this cable suitable for sensors in outdoor environments?
  A:Yes, the PVC sheath offers reliable protection in most indoor and covered outdoor areas.
• Q:Can it be used for data transmission?
  A:Yes, it handles both signal and power for sensors and small devices.
• Q:What torque should I apply to the connector?
  A:Use 0.6 Nm as recommended for secure locking.
• Q:How flexible is the cable for movement applications?
  A:It supports a bending radius of at least 10× its sheath diameter, ideal for flexible setups.
• Q:What’s the best installation tip?
  A:Avoid tight loops and maintain proper strain relief for longer cable life.
