Product details
Compact Power for Your Machine
The Lenze E94ASHE0034 is a versatile and robust AC drive. It delivers 0.75 kW of reliable power for various industrial applications. This drive from the Series 9400 fits perfectly into automation systems requiring precise motor control.
Core Technical Specifications
Identification & Ratings
- Brand: Lenze
- Model: E94ASHE0034
- Series: 9400
- Rated Power: 0.75 kW (1 HP)
- Input Voltage: 3-Phase, 230 / 400 / 500 VAC, 50/60 Hz
- Output Voltage: 0 – Input Voltage (230/400/500 VAC)
Performance & Control
- Output Frequency: 0 – 480 Hz
- Control Modes: Speed, Torque, Position
- Switching Frequency: 8 kHz (typical)
- Overload Capacity: 150% for 60 seconds
- Braking Chopper: Integrated
Physical & Environmental
- Protection Class: IP20
- Cooling: Forced Ventilation
- Operating Temperature: 0°C to +40°C
- Compliance: CE, UL, cUL
Top Product Features
- Wide Voltage Range: Connects to 230V, 400V, or 500V three-phase supplies. It offers great installation flexibility.
- Multi-Control Modes: Handles speed, torque, and position control for diverse application needs.
- High Overload Capacity: Manages temporary load peaks (150% for 60s) without tripping.
- Integrated Braking: The built-in braking chopper allows for faster motor stopping.
- Network Ready: Supports CANopen, PROFIBUS, and EtherCAT communication via optional modules.
Order & Support Details
- Warranty: All products include a 12-month warranty.
- Shipping: Fast worldwide delivery via FedEx, UPS, and DHL.
- Author: Powergear X Automation
Professional FAQs
- Can the E94ASHE0034 drive a standard 400V 3-phase motor?
- Yes, absolutely. Set the input voltage parameter to 400V. The drive will then output the correct voltage to your motor.
- What is the main benefit of the integrated braking chopper?
- It allows you to connect a braking resistor directly. This dissipates energy during quick stops, preventing drive faults.
- Is an optional keypad required for setup?
- For initial commissioning, yes. You need a keypad or PC software to set basic parameters. After setup, the drive can run standalone.
- The motor is in a dusty area. Is IP20 sufficient?
- IP20 protects against finger contact but not dust or water. Install the drive in a clean, protected control cabinet (IP54 or higher).
- Can I get precise positioning with this drive?
- Yes, in position control mode with a feedback encoder. Use the optional feedback module and configure the drive accordingly.
