ICS Triplex T9451 Digital Output Module

The ICS Triplex T9451 is a compact 8-channel 24Vdc output module built for Trusted control systems.
It provides isolated outputs, fast response, and stable performance for demanding automation environments.

Performance Summary

• 8-channel digital output with individual isolation and common return lines.
• Simplex Scan: 1.174 ms for fast single-processor operation.
• Dual Scan: 2.202 ms for high-integrity dual configuration.
• Power Dissipation: 3.0 W (10.2 BTU/hr).
• Each output supports 18–32 Vdc @ 0.5 A continuous, 1.5 A inrush current.

Electrical Ratings

• Back-plane Voltage Range: 18–32 Vdc
• Maximum Current Draw: 165 mA
• Power Consumption: 3.0 W typical
• Pilot Duty: 16 VA for output relay circuits
• Heat Dissipation: 10.2 BTU/hr ensures thermal balance

Technical Specifications

• Brand: ICS Triplex
• Model: T9451
• Type: Digital Output Module
• Output Channels: 8, isolated, commoned
• Voltage Range: 18–32 Vdc
• Output Current: 0.5A per channel
• Fuse Rating: Internal electronic protection circuit
• Response Time: < 2 ms typical
• Operating Temp: –20°C to +70°C
• Storage Temp: –40°C to +85°C
• Weight: 340 g (12 oz.)
• Mounting: Plug-in module for Trusted I/O chassis
• Warranty: 12 months standard

Why Choose T9451?

• Fast scan cycles for precise output response.
• Isolated design improves safety and reduces cross-talk interference.
• Compact 8-channel format saves cabinet space.
• Low power consumption ensures energy efficiency.
• Trusted platform compatibility for long-term system reliability.

Installation & Usage

• Insert the T9451 module into the designated Trusted I/O chassis slot.
• Connect field wiring to the labeled terminals for each output channel.
• Ensure voltage supply is within 18–32 Vdc before powering up.
• Maintain air clearance around the module for thermal ventilation.

Shipping & Warranty

• All products include a 12-month warranty for factory defects.
• Secure worldwide shipping via FedEx, UPS, or DHL.
• Each module is tested and packaged with anti-static protection.

FAQ

• Q: What is the voltage range for the T9451?
  A: It operates between 18 and 32 Vdc.
• Q: How many output channels are available?
  A: The module provides 8 independent output channels.
• Q: What is the output current per channel?
  A: Each channel supports 0.5A continuous and 1.5A inrush current.
• Q: Is the module isolated?
  A: Yes, each output is isolated for improved system safety.
• Q: What is the typical power use?
  A: The module consumes only 3.0W, ensuring energy-efficient operation.
