ICS Triplex T8311 — Trusted TMR Expander Interface Module

The T8311 Expander Interface from ICS Triplex enables fast, reliable communication between the Trusted Controller and Expansion Chassis. Designed for the Trusted TMR System, it ensures stable performance, high data throughput, and safe operation across complex control environments.

Core Specifications

• Brand: ICS Triplex
• Model: T8311
• Type: Trusted TMR Expander Interface
• Voltage Range: 20–32 VDC
• Power Rating: 54 W
• Heat Dissipation: 40 W max
• Bus Speed: 250 Mbps Expander Bus
• Clock Speed: 50 MHz
• Use With: Chassis Model T8300
• I/O Interface: Expander chassis backplane
• Operating Temp: -5°C to 60°C (13°F to 140°F)
• Storage Temp: -25°C to 70°C (-13°F to 158°F)
• Humidity: 5–95% RH (non-condensing)
• Dimensions: 30.3 × 3.1 × 26.6 cm
• Weight: 1.14 kg
• Certifications: ATEX / IECEx / Ord / HazLoc
• Warranty: 12 months standard

Performance Features

• High-speed 250 Mbps data transmission ensures seamless TMR communication.
• Robust build supports extended temperature and humidity ranges.
• Compact 1.14 kg design fits securely in control racks.
• Efficient 54 W operation minimizes heat output.
• Ideal for redundant Trusted TMR setups requiring long cable links up to 50 m.

System Integration

• Works with T8100 Controller Chassis and CS300 Expander Chassis.
• Connects via T8312 Expander Interface Adapter and TC-324-02 PCB.
• Supports triple bidirectional links using TC-322-02 cables.
• Compatible with T8310 and T8314 for multi-chassis communication paths.

Reliability & Safety

• Maintains stable operation under vibration and humidity variations.
• Prevents communication loss and reduces risk of spurious trips.
• Meets IEC61511 testing for communication integrity verification.
• Field-tested for industrial automation, oil, and power applications.

Packaging & Delivery

• 1 × T8311 Expander Interface Module
• 1 × Quick Installation & Safety Manual
• Packed with anti-static protection and shock-resistant foam
• Delivery via FedEx, UPS, or DHL

FAQ

• Q: What voltage range does the T8311 support?
  A: It operates safely from 20 to 32 volts DC.
• Q: How fast is the data communication rate?
  A: The module supports 250 Mbps expander bus data speed.
• Q: What chassis is compatible with this interface?
  A: The T8311 connects with the Trusted T8300 chassis.
• Q: Can it operate in hot industrial environments?
  A: Yes, it performs reliably up to 60°C (140°F) ambient temperature.
• Q: What standards does it comply with?
  A: Certified for ATEX, IECEx, Ordinary, and Hazardous Locations.
