ICS Triplex T8151 Trusted Communications Interface
The T8151 Communications Interface connects Trusted TMR systems with field networks and peer devices. It enables secure and efficient data transfer using Modbus, Ethernet, and serial protocols across critical automation applications.
Quick Highlights
- Model: T8151
- Power Supply: 20 – 32 V DC, 14 W
- Ports: 2 Ethernet (10/100BaseT), 4 RS-232/422/485 serial, 1 diagnostic port
- Protocol Support: Modbus RTU, Open Modbus TCP, Trusted Peer to Peer
- Isolation: Up to 250 V basic insulation between Ethernet and serial interfaces
- SOE Buffer: 4000 events
- Operating Temp: 0 °C – 60 °C (32 °F – 140 °F)
- Storage Temp: -25 °C – 70 °C (-13 °F – 158 °F)
- Humidity Range: 10% – 95%, non-condensing
- Certifications: Ord, HazLoc, ATEX, IECEx
Key Advantages
- Reliable Modbus and Ethernet integration for high-performance control systems.
- Supports multiple simultaneous communication channels for redundancy.
- Enhanced Peer-to-Peer communication ensures fast data synchronization.
- Built-in diagnostic port simplifies setup and monitoring.
- Compact and lightweight design: 266 × 31 × 303 mm, only 1.13 kg.
- Optimized power usage with 10 W heat dissipation under normal load.
- Backplane supply isolation for improved system safety.
Specifications Summary
- Brand: ICS Triplex
- Model: T8151
- Function: Trusted Communications Interface Module
- Installation Slot: T8100 / T8300 I/O Module Slot
- Voltage Input: 20 – 32 V DC
- Power Use: 14 W
- Fusing: Internal, non-user serviceable
- Dimensions: 266 mm (H) × 31 mm (W) × 303 mm (D)
- Weight: 1.13 kg (2.49 lb)
- Warranty: 12 months
Performance & Connectivity
- Dual Ethernet and serial ports allow simultaneous Modbus TCP and RTU communication.
- Baud rate up to 115200 baud for rapid data exchange.
- Peer-to-peer communication supports distributed control configurations.
- Designed for high-reliability industrial and hazardous environments.
Shipping Details
- Secure worldwide shipping via FedEx, UPS, or DHL.
- Protective anti-static and shock-resistant packaging.
- Global delivery available, typically within 2–4 business days.
FAQ
- What communication protocols does the T8151 support?
It supports Modbus RTU, Modbus TCP, and Trusted Peer-to-Peer communications. - Can it work with both T8100 and T8300 chassis?
Yes, it fits both Trusted I/O module slots for easy installation. - Is the module certified for hazardous locations?
Yes, it is approved for Ord, HazLoc, ATEX, and IECEx environments. - What is the typical power consumption?
The T8151 operates efficiently at 14 W with minimal heat output. - How many serial connections are available?
It provides four rear serial ports and one front diagnostic port.
