ICC316 Trip Amplifier | 4-20mA/1-5V Input | Relay Outputs

ICC316 General Purpose Indicating Trip Amplifier

This is a versatile and low-cost trip amplifier. It provides precise monitoring and alarm relay outputs. It is perfect for industrial automation systems.

Technical Data

• Brand: ICC
• Model: ICC316 Series
• Input Signals: 4-20mA, 1-5V DC
• Measurement Range: 0 to 100%
• Display Accuracy: < 0.1% of span
• Trip Accuracy: < 0.2% of span
• Response Time: Relay: 300ms, Display: 700ms
• Resolution: 3.5 digits
• Linearity: < 0.1% of span
• Hysteresis: 1.5% of span (typical)
• Power Supply: 20-35V DC
• Relay Contact: 10A, 250V AC / 30V DC
• Operating Temperature: -20°C to +55°C
• Storage Temperature: -40°C to +80°C
• Environmental Resistance: 5-95% RH, non-condensing
• Interference Immunity: Conforms to IEC801.3
• Isolation: 1500V DC/AC

Ordering Information

Choose the right model for your application:

• ICC316-T1: One set-point, One SPST output
• ICC316-T2: Two set-points, Two SPST outputs
• ICC316-T3: One set-point, One DPST output

Installation and Setup

• Mounts easily on standard T or G-section DIN-rails
• Terminals accept wires up to 2.5mm²
• Set-points are adjusted with multi-turn trimpots
• Phase reversal switches are on the top

Certification & Packaging

• Conforms to IEC801.3 standards
• Package includes the ICC316 unit only
• Warranty: 12 months
• Shipping via FedEx, UPS, or DHL

Frequently Asked Questions (FAQ)

• Q: What input signals does it accept?
  A: It accepts 4-20mA current and 1-5V voltage signals.
• Q: Can I use it to power a transmitter?
  A: Yes, it provides a 20V/20mA power supply for transmitters.
• Q: What is the hysteresis value?
  A: Approximately 1.5% to prevent relay hunting.
