IC698CHS009 GE Fanuc | I/O Rack

Overview

The GE Automation IC698CHS009 is a rear-mounted, 9-slot rack designed for housing RX7i and Series 90-70 modules and CPUs. It offers flexibility in module placement, supporting both single-width and double-width modules. The rack has built-in features such as slot sensing, automatic daisy chaining for interrupt acknowledge and bus grant signals, and J2 connectors that support speeds up to 64 bits per cycle. It’s compatible with RX7i power supplies and cooling fans, ensuring efficient cooling when necessary.

Features

• Module Slots: 9 slots (8 single-width, 1 double-width)
• Automatic Daisy Chaining: For interrupt acknowledge and bus grant signals
• Cooling Compatibility: Supports cooling fans for high-power modules
• Slot Sensing: No DIP switches or jumpers required for module addressing
• Speed: J2 connectors with 64-bit cycle speeds
• Grounding: Features grounding options for safety and EMI reduction
• Power Supply: Compatible with RX7i power supplies in Slot 0

Technical Specifications

• Brand: GE Automation
• Model: IC698CHS009
• Dimensions: 11.15″ (H) x 12.6″ (W) x 7.25″ (D)
• Module Slot Size: 0.8″ per slot (20.3mm)
• Power Supply: Slot 0 (2.4″ wide) for RX7i power supply
• Current Output (100W): +5V: 20A, +12V: 2A, -12V: 1A
• Current Output (350W): +5V: 60A, +12V: 12A, -12V: 4A
• Cooling Fans: Optional, for high-power modules like IC698CPE020, IC698CRE020, and IC698PSA350
• VME64 Support: Designed to support VME64

FAQ

1. What modules can be installed in this rack?
   It supports RX7i and Series 90-70 modules, with slots available for single or double-width modules.
2. Is a cooling fan necessary for all modules?
   Cooling fans are required for high-power modules like IC698CPE020, IC698CRE020, and IC698PSA350.
3. What is the required ground wiring?
   The rack must be grounded using AWG #12 wire connected to the earth ground.
