CANopen Network Hub: GE Fanuc IC695CNM001 Master Module
Connect and control industrial devices effortlessly! This RX3i module masters CANopen networks with 1Mbps speed and 5-slave capacity. Hot-swappable design keeps production running during maintenance.
Technical Specifications
| Brand & Series | GE Fanuc • RX3i PacSystems |
| Full Model Numbers | IC695CNM001, IC695CNM001-AA, IC695CNM001-BB |
| Slave Capacity | 5 devices per module |
| Data Throughput | 272 bytes TX/RX PDO scanning |
| Baud Rate Range | 10 kbps to 1 Mbps (adjustable) |
| Power Consumption | 800mA @ 3.3VDC backplane |
| Frame Type | 11-bit CAN frame |
| Operating Temp | 0°C to 60°C (32°F to 140°F) |
| LED Indicators | POWER • MOD Status • NET Status |
Installation Guide
- Power ON system (hot-swap supported)
- Insert into RX3i main rack – Avoid Slot 0
- Connect CANopen devices via 9-pin D-sub
- Configure network using SYCON.NET software
- Verify LED status: Green POWER = Operational
Compatibility Notes
- Requires: RX3i CPU firmware 7.70+
- Software: SYCON.NET for configuration
- Works With: All standard CANopen slave devices
Package & Warranty
- 1 × IC695CNM001 Module
- Installation guide
- 12-Month Warranty
- Global Shipping: FedEx • UPS • DHL (2-4 days)
Expert FAQs
Q: What do flashing NET LEDs indicate?
A: Flashing yellow = Network errors • Check baud rate and termination .
Q: Can I connect more than 5 slaves?
A: No – 5 is maximum. Add secondary module for larger networks .
Q: How to configure PDO mapping?
A: Use SYCON.NET software via USB Mini-B port .
Q: Why avoid Slot 0?
A: Reserved for CPU modules – may cause address conflicts .
