GE Fanuc IC694PSK001 Power Sync and Measurement Kit for RX3i

Product Overview

The IC694PSK001 is a power sync and measurement kit for RX3i systems. It measures power data from up to two power grids. It includes one PSM module, one terminal assembly, and two cables. It helps monitor voltage, current, frequency, and power flow between grids.

Key Technical Data

• Voltage Range: Up to 690 VAC RMS
• Current Rating: Up to 15 Amps
• Voltage Accuracy: ±0.2%
• Power Supply: 5 VDC, 400 mA
• Digital Output: 2 relay outputs, 125 VAC/DC
• DSP Technology: Supported
• Relay Rating: 1 Amp at 125 VAC or 125 VDC
• Cable Length: 6.5 feet (2 meters)
• LEDs: RUN, FLT, GRID 1, GRID 2
• Input Type: Current transformers (CT) and potential transformers (PT)

Measured Parameters

• RMS Voltage
• RMS Current
• RMS Power
• Frequency
• Phase angle between grids

Installation Guide

• Mounts to RX3i backplane
• Terminal assembly is panel-mounted
• Cables connect PSM to terminal unit
• Check cable connection with built-in cable check
• Use Proficy software for setup

Package Includes

• 1 x PSM Module (IC694PSM001)
• 1 x Terminal Assembly (IC694ACC200)
• 2 x Interface Cables (IC694CBL200)
• 12-month warranty
