GE Fanuc IC694MDL940 16-Point Relay Output Module for RX3i PACSystems
Product Overview
The IC694MDL940 is a 16-point relay output module for RX3i PACSystems. It has 4 groups of 4 channels. Each channel uses a Normally Open (Form A) contact. This module supports both AC and DC loads. It is used to control motors, solenoids, and lights in many industrial systems.
Main Technical Details
- Output Channels: 16 isolated Form A (N.O.) relays
- Groups: 4 groups with 4 outputs each
- Voltage Range: 5–30 VDC or 5–250 VAC
- Nominal Voltage: 24 VDC, 120/240 VAC
- Max Load: 2 Amps per channel, 4 Amps per group
- Min Load: 10 mA per output
- Inrush Current: 5 Amps max
- Backplane Draw: 7 mA (5V), 135 mA (24V)
- Response Time: 15 ms (on/off)
- Relay Life: 100,000 to 1,000,000 operations
- Isolation: 250 VAC continuous; 1500 VAC for 1 min
Installation Guidelines
- Install in any RX3i I/O slot
- Use external power for output devices
- Supports standard 50/60 Hz systems
- No internal fuse; external protection is advised
Warranty and Shipping
- 12-month warranty
- Ships with FedEx, UPS, or DHL
- Safe packaging for fast global delivery
Problem Solving Features
- Easy group wiring reduces panel clutter
- Handles AC and DC loads in one module
- Strong channel isolation for high-safety zones
- Quick replacement for legacy relay modules
