IC694MDL916 GE Fanuc RX3i Voltage Output Module

GE Fanuc IC694MDL916 Relay Output Module for RX3i PLC

Product Overview

The IC694MDL916 is a relay output module for RX3i PLCs. It has 16 isolated outputs. Each output uses a Normally Open contact. It supports both AC and DC loads.

Main Features

• Model: IC694MDL916
• Outputs: 16 isolated Form A (Normally Open)
• Output Voltage: 5–250 VAC or 0–125 VDC
• Current: Up to 4 A per output
• Min Current: 10 mA per point
• Switching Rate: 20 times per minute
• Response Time: 10 ms
• Relay Life: Up to 1,000,000 operations
• Backplane Current: Max 300 mA at 5 VDC
• LEDs: One per output

Installation Guide

• Mounts in RX3i I/O slots
• Needs external power (AC or DC)
• Use terminal blocks: IC694TBB032, TBS032, TBB132, or TBS132
• Uses DIP switch to set default output mode

Compatibility

• Works only with RX3i CPUs
• Not for Series 90-30 systems

Real-World Uses

• Controls solenoids, motors, lights, and alarms
• Great for machines, panels, and plant automation
• Reliable switching for mixed AC/DC loads
• Built-in protection for faults and power issues

Package Contents

• IC694MDL916 Output Module
• Quick install guide
• 12-month warranty
