IC694MDL730 GE Fanuc RX3i Voltage Output Module

GE Fanuc IC694MDL730 12-24V DC Output Module for RX3i PACSystem

Overview

The IC694MDL730 is an 8-point DC output module from the GE Fanuc RX3i PACSystem series. It works at 12–24V DC and sends output signals to control devices like indicators or motor starters. Each output has LED status lights, and the module includes dual 5A fuses for protection.

Key Technical Specifications

• Model: IC694MDL730
• Type: Output Module
• Voltage: 12–24V DC (±20%/+15%)
• Output Points: 8 (1 group)
• Output Current: 2A max per point
• Inrush Current: 9.4A (10 ms)
• Voltage Drop: Max 1.2V
• Isolation: 1500V field-to-logic
• Response Time: 2 ms max
• Power Use: 55 mA total

Extended Operating Parameters

• Derating: Current decreases with temperature rise
• Current at 50°C: 4A
• Current at 60°C: 2A
• Thermal Protection: 2 x 5A fuses (shared)

Installation Guide

• Mount on RX3i I/O rack
• Uses shared positive bus output wiring
• Works with DC-powered actuators and loads
• Secure connections with field wiring terminal blocks

Package Includes

• 1 x IC694MDL730 Output Module
• 2 x 5A built-in fuses
• Installation note
• Warranty: 12 months
