IC694MDL754: 32-Point DC Output Powerhouse
Ultra-Fast Industrial Control
32-output RX3i module by GE Fanuc/Emerson. Delivers 0.75A per point at 12-24VDC with auto-recovery protection. Perfect for high-speed automation.
Technical Specifications
| Brand | GE Fanuc/Emerson | Response Time | 0.5ms |
| Model | IC694MDL754 | Output Groups | 2 isolated × 16 |
| Series | PACSystems RX3i | Voltage Range | 10.2-30VDC |
| Current/Point | 0.75A | Backplane Power | 300mA @5V |
| Inrush Current | 3A (10ms) | Leakage Current | 0.1mA max |
| Isolation | 1500VAC/1min | Firmware Requirement | v2.90+ |
Installation Guide
- Verify CPU firmware ≥ v2.90
- Mount in any RX3i slot
- Select terminal block style
- Connect 12-24VDC power
Package Contents
- IC694MDL754 module
- Installation guide
- Static-safe packaging
Shipping & Warranty
FedEx | UPS | DHL – 3-5 business days
12-month warranty included
Frequently Asked Questions
Q: Can I use 12V and 24V simultaneously?
A: No – entire module uses same voltage
Q: Maximum load per group?
A: 12A (16 points × 0.75A)
Q: Compatible with LED lighting?
A> Yes – ideal for low-power DC loads
