IC694MDL260: High-Density 120VAC Input Module
Smart Industrial Input Solution
32-channel PACSystems RX3i input module by GE Fanuc (now Emerson). Handles 120VAC industrial signals with 4 isolated groups. Perfect for machine control with advanced diagnostics.
Key Specifications
| Brand | GE Fanuc/Emerson | Channels | 32 |
| Model | IC694MDL260 | Input Voltage | 0-132VAC |
| Series | PACSystems RX3i | Current/Channel | 7mA |
| Isolated Groups | 4 groups × 8 | Backplane Power | 220mA @5V |
| On-State Voltage | 70-132VAC | Response Time | ≤840ms |
| Temp Range | 0°C to 50°C | Isolation | 1500VAC/1min |
Top Features
- Group isolation – 1 group fails, others work
- Real-time diagnostics reports to CPU
- Adjustable filter time (20-2540ms)
- DIP switch for quick setup
Quick Install Guide
- Power OFF PLC system
- Slot into any RX3i base
- Connect devices to isolated groups
- Set DIP switch for filter time
Package Contents
- IC694MDL260 module
- Installation guide
- Static-safe packaging
Global Shipping
FedEx | UPS | DHL – Delivered in 2-5 days
Common Questions
Q: Can I use different voltages per group?
A: Yes! Each group handles 70-132VAC separately
Q: Minimum on-time for sign
al detection?
A: 20ms with fastest filter setting
Q: Compatible with Series 90-30?
A: Yes – works with both RX3i and 90-30 PLCs
