IC694MDL240 GE Fanuc RX3i AC Voltage Input Module

IC694MDL240: 16-Channel 120VAC Input Module

Description

Upgrade your PACSystem RX3i with the IC694MDL240 – a reliable 16-channel AC input module. Designed for industrial environments, it features 120VAC operation with optical isolation (1500VAC rating). Perfect for monitoring switches, sensors, and control devices in manufacturing and energy systems.

Technical Data

• Brand: GE Fanuc (Emerson)
• Model: IC694MDL240
• Series: PACSystem RX3i
• Input Channels: 16 points (1 common group)
• Voltage Range: 0-132VAC
• Nominal Voltage: 120VAC
• Frequency: 47-63 Hz
• On-State Voltage: 74-132VAC
• Response Time: 30ms (On) / 45ms (Off)
• Current per Channel: 12mA @120VAC
• Isolation: 1500VAC (1 minute)

Installation Guide

• Mount in any RX3i local/remote slot
• Connect to 120VAC power source
• Single common terminal for all inputs
• Ensure ambient temperature <60°C

Diagnostics & Maintenance

• 16 LEDs (1 per channel) for instant status
• Check input voltage stays within 74-132VAC
• Monitor for sustained current >12mA
• Verify wiring at common terminal

Packaging List

• IC694MDL240 Input Module ×1
• Mounting hardware kit
• Quick-start guide

Shipping

Delivered via FedEx, UPS, or DHL. Tracking provided upon shipment.

FAQ

Q: Can I use this with 240VAC systems?
A: No! Max input is 132VAC.

Q: Are channels individually isolated?
A: No – all 16 channels share one common terminal.

Q: What triggers the input LED?
A: LED lights when voltage >74VAC is detected.
