IC694ALG390 ±10V Analog Output Module
PRODUCT OVERVIEW
GE Fanuc’s IC694ALG390 delivers precision ±10V analog outputs for RX3i systems. Dual-channel design converts digital signals to analog for industrial control. Compatible with all RX3i CPUs. No hot-swap support!
TECH SPECS
| Brand | GE Fanuc |
| Output Channels | 2 |
| Voltage Range | -10V to +10V |
| Resolution | 13-bit |
| Power @5V DC | 32mA (0.16W) |
| Power @24V DC | 120mA (2.88W) |
INSTALLATION GUIDE
- Install in any open slot on compatible backplanes
- Compatible with:
– RX3i Serial Expansion Backplane
– Series 90-30 Expansion Backplane - POWER OFF SYSTEM before installation
- Connect field devices to output terminals
- Allow proper ventilation space
POWER MANAGEMENT
| Voltage | Current | Power | Use Case |
|---|---|---|---|
| 5V DC | 32mA | 0.16W | Module electronics |
| 24V DC | 120mA | 2.88W | Output signal generation |
PACKAGE CONTENTS
- IC694ALG390 Output Module
- Mounting hardware
- Installation guide
FAQ
Q: Can I install while system is running?
A: No! Power must be off – risk of damage.
Q: What devices can it control?
A: VFDs, control valves, actuators – any ±10V compatible device.
Q: Resolution accuracy?
A: 13-bit precision = 0.012% of full scale.
