IC693MDL750 GE Fanuc Series 90-30 Voltage Output Module

GE Fanuc IC693MDL750 32-Point Negative Logic Output Module for 90-30 PLC

Overview

The IC693MDL750 is a 32-point negative logic output module made for GE Fanuc Series 90-30 PLCs. It uses a 50-pin connector for wiring and provides fast response in industrial automation tasks. Designed for use with DC loads, this module is a good fit for control systems requiring high-density outputs.

Main Features

• Total Outputs: 32 points
• Voltage Rating: 12 to 24 VDC
• Logic Type: Negative
• Connector Type: 50-pin front-mounted
• Groups: 4 groups of 8 outputs
• Commons: 2 common pins per group
• LED Indicators: Not included

Technical Specifications

• Current Draw from 5V Bus: 21 mA
• Max Current per Point: 0.3 Amps
• Max Current per Common: 2 Amps at 60°C
• Peak Output Voltage Drop: 0.24 Volts
• Output Type: Sinking

Installation Instructions

• Fits in any slot on a 5-slot or 10-slot Series 90-30 baseplate
• Use 50-pin connector for all output wiring
• Install in IP54-rated enclosure for protection
• Ensure proper load power is supplied externally

What’s Included

• 1 x IC693MDL750 Output Module
• Factory-sealed packaging
• Installation leaflet (if applicable)
• No certificates included
• 12-month warranty
