GE Fanuc IC693CMM321 Ethernet Interface: Advanced PLC Networking
Powerful Ethernet module for Series 90-30 PLC systems. 16 server connections with triple-port architecture. Note: Discontinued product.
Core Specifications
- Brand: GE Fanuc
- Model: IC693CMM321
- Port Configuration:
- AAUI Network Port (Ethernet)
- RS-232 RJ-11 (Station Manager)
- RS-485 15-pin (Software Loader)
- Max Connections: 16 server connections
- CPU Requirements: Version 6.50+ (full features)
Technical Features
- LED Indicators: OK, LAN, SER, STAT
- Network Protocol: TCP/IP Ethernet
- Simultaneous Operations: Data transfer, diagnostics, multi-device comms
- Module Width: Single slot
- Accessories: AAUI cable + external transceiver
Compatibility & Requirements
- Full Functionality: CPU v6.50+
- Limited Functionality: CPU v5.03-6.04 (1 SRTP connection only)
- Configuration Software:
- Logicmaster 90-30 v6.01+
- Control v2.01+
- VersaPro v1.0+
Installation & Limitations
- Baseplate: Max 2 modules per chassis
- Not Compatible: Series 90-30/20/Micro handheld programmers
- LED Functions:
- OK: Module status
- LAN: Network traffic
- SER: Downloader port activity
- STAT: Exception events
Product Status & Support
- Status: Discontinued/Obsolete
- Warranty: 12 months
- Global Shipping: FedEx, UPS, DHL
- Module ships without accessories
FAQ
Q: What CPU version is required for full features?
A: Version 6.50 or higher
Q: How many modules per PLC rack?
A: Maximum of 2 Ethernet modules
Q: What’s the AAUI port for?
A: Ethernet network connection (requires transceiver)
Q: Is this still available new?
A: No – discontinued but available from surplus stock
