IC693ALG223 | GE Fanuc RX3i Analog Input Module

GE Fanuc IC693ALG223 16-Channel Analog Current Input Module

Technical Details

• Input Range: 0-20 mA, 4-20 mA, 4-20 mA Enhanced
• Channels: 16 single-ended
• Resolution: 12-bit; 4 µA at 4-20 mA, 5 µA at 0-20 mA
• Accuracy: ±0.25% at 25°C; ±0.5% over full temperature range
• Isolation: 1500 V RMS between field and logic
• Update Rate: 13 ms for all channels
• Input Impedance: 250 ohms
• Input Filter: 200 Hz
• Power: External 24 VDC (20-30 V, max 10% ripple)
• Power Use: 120 mA at 5 VDC, 65 mA at 24 VDC
• Working Temp: 0 to 60°C

How to Install

• Fits any slot in 5-slot or 10-slot baseplates
• Max modules per system: 4 (CPU 311/313/323), 8 (CPU 331), 12 (CPU 340/341), 51 (CPU 351/352)
• Use shielded cables to cut noise

Compatibility

• Works with Series 90-30 PLCs and remote I/O racks
• Supports many industrial sensors like flow, level, and temp

Package Includes

• 1 x IC693ALG223 Analog Current Input Module
• 12-month warranty
• No certificates included

Shipping Info

• Ships with FedEx, UPS, DHL
• Fast delivery with tracking
